JST B6PSHF1AALFSN Connector Header
This 6-position connector header from the NH Series features a 2.5mm pitch and a top entry design, providing reliable PCB-to-branch connectivity. Suitable for 30-22 AWG wire gauges, it is rated for up to 250V voltage and 3A current, with excellent insulation resistance of 500MΩ and withstand voltage of 1,500V AC. Made of durable materials like brass with tin-plated contact surfaces and UL94V-2 approved PA66 housing, it offers a stable, RoHS-compliant solution for electronic circuit connections. Ideal for various electronic and industrial applications requiring secure connections and long-term reliability.
JST B6PSHF1AALFSN Connector Header Specifications:
- Number of positions: 6
- Pitch: 2.5mm
- Current rating: 3A AC/DC
- Voltage rating: 250V AC/DC
- Applicable wire gauge: 30-22 AWG
- Material (contacts): Brass, tin-plated (reflow treatment)
- Housing: UL94V-2, PA66, natural
- Temperature range: -25°C to +85°C
- Insulation resistance: 500MΩ minimum
- Withstand voltage: 1,500V AC/minute
- RoHS compliant
Buy the Buy JST NH Series Connector Part Number B6PSHF1AALFSN Online
Purchase the JST NH Series connector header B6PSHF1AALFSN online today to ensure your electronic projects benefit from high-quality, reliable PCB connections. Featuring a 2.5mm pitch and rated for up to 250V and 3A, this durable component is ideal for a wide range of industrial and electronic applications. Its robust construction, RoHS compliance, and precise design make it a trusted choice for engineers and technicians seeking long-term connectivity solutions. Order now and elevate your assembly quality with JST's proven reliability.
Buy JST NH Series connector header B6PSHF1AALFSN now and experience unmatched reliability and performance in your electronic applications.
Frequently Asked Questions
Where can I buy JST B6PSHF1AALFSN?
You can click on the BUY or RFQ button to purchase B6PSHF1AALFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B6PSHF1AALFSN?
You can download the B6PSHF1AALFSN datasheet or visit the JST website for support.
Who is the manufacturer of B6PSHF1AALFSN?
JST
