JST BM02BASRSTFLFSN Connector Housing
This 2-position connector housing from the ASR series is engineered for reliable electrical connections in industrial and automation applications. Rated for 50V DC and compatible with 30 AWG wire, it features a shrouded design for secure connections and tin-plated contact surfaces for enhanced corrosion resistance. Made from UL94V-0-rated glass-filled PA 66, it ensures durability and safety in harsh environments. Suitable for vacuum pick-and-place robotics, this connector offers a compact, RoHS-compliant solution for PCB interconnections and electronic control systems.
JST BM02BASRSTFLFSN Connector Housing Specifications:
- Current rating: 0.7A DC
- Voltage rating: 50V DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/30mΩ max, after testing/40mΩ max
- Insulation resistance: ≥100MΩ
- Withstanding voltage: 500V AC/minute
- Applicable wire: Conductor size/AWG 30, 7 strands, tin-coated copper
- Insulation O.D.: 0.54 to 0.58mm
- Housing material: Glass-filled PA 66, UL94V-0, natural color
- Contact material: Phosphor bronze, tin-plated
- Solder tab: Brass, tin-plated
- RoHS compliant
- Designed for vacuum pick-and-place robotics
- Standards: Recognized E60389, certified LR20812
Buy the JST 2.0–Reliable Connection Housing for Industrial Applications
Purchase the JST SeriesBM02BASRSTFLFSN connector housing online today and enjoy reliable, corrosion-resistant connections suitable for industrial automation, electronics, and PCB applications. Featuring a shrouded design for secure mating, tin-plated contacts for longevity, and UL94V-0-rated durable material, this compact connector ensures safe, efficient, and RoHS-compliant performance in harsh environments. Ideal for robotics, control systems, and electronic devices, order now to enhance your project's reliability with quality JST connectors delivered promptly.
Order your JST SeriesBM02BASRSTFLFSN connector today and ensure secure, corrosion-resistant connections for your industrial projects.
Frequently Asked Questions
Where can I buy JST BM02BASRSTFLFSN?
You can click on the BUY or RFQ button to purchase BM02BASRSTFLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part BM02BASRSTFLFSN?
You can download the BM02BASRSTFLFSN datasheet or visit the JST website for support.
Who is the manufacturer of BM02BASRSTFLFSN?
JST
