JST PUDP10VK Connector housing
This 10-position connector housing features a 2.0 mm pitch and a secure locking mechanism to ensure stable electrical connections, even under vibrations. Made of high-quality PBT with UL94V-0 flame retardant rating, it supports voltage ratings up to 250V AC/DC and current up to 3A. Compatible with wire sizes AWG 28 to 22, it includes a polarizing key for proper mounting on PC boards. The connector is RoHS compliant, available in natural color, and suitable for electronic applications requiring reliable, snap-in connections.
JST PUDP10VK Connector housing Specifications:
- Current rating: 3A AC/DC (AWG#22)
- Voltage rating: 250V AC/DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial/10mΩ max, after testing/20mΩ max
- Insulation resistance: 1000MΩ min
- Withstanding voltage: 800V AC/minute
- Applicable wire: AWG #26 to #22
- Material: PBT, UL94V-0, natural color
- RoHS compliant
- Connector type: Top entry
- Locking device: Secure locking structure
Buy the JST Series Connectors: Secure 10-Position 2.0mm Pitch Locking Connector: PUDP10VK
Enhance your electronic assemblies with this 10-position connector housing featuring a 2.0mm pitch and secure locking mechanism. Made from flame-retardant PBT material, it supports voltage ratings up to 250V and a current of 3A, compatible with wire gauges AWG 28 to 22. Its RoHS compliance ensures environmentally friendly use, and the natural color seamlessly integrates into various electronic devices. Ideal for PCB mounting with polarizing key for correct orientation, this connector guarantees stable, vibration-resistant connections for reliable operation.
Order your JST Series PUDP10VK connector housing today and ensure reliable, vibration-resistant electrical connections for your electronic projects.
Frequently Asked Questions
Where can I buy JST PUDP10VK?
You can click on the BUY or RFQ button to purchase PUDP10VK from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part PUDP10VK?
You can download the PUDP10VK datasheet or visit the JST website for support.
Who is the manufacturer of PUDP10VK?
JST
