JST PUDP20VS Rectangular Connector Housing
A set of 20 rectangular connector housings designed as receptacles in a natural color. Each connector is suitable for 2.00 mm pitch applications, providing reliable and secure connections for electronic components.
JST PUDP20VS Rectangular Connector Housing Specifications:
- Current rating: 3A AC, DC (AWG#22)
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/10mΩ max, after environmental testing/20mΩ max
- Insulation resistance: 1,000MΩ minimum
- Withstanding voltage: 800V AC/minute
- Applicable wire: AWG #26 to #22 (type 001), AWG #28 to #24 (type 002)
- Material: Copper alloy, tin-plated (reflow treatment)
- Connector format: Receptacle, natural color
- RoHS compliant
- Suitable for surface-mount technology (SMT), top entry type
- Dimensions vary with circuit number, e.g., 8 circuits - 60mm length, 10 circuits - 80mm length, up to 40 circuits - 420mm length
Buy the Buy JST PUDP20VS Part Number PUDP20VS Online
Purchase the JST PUDP20VS connector housing online and enjoy a secure, reliable connection for your electronic assemblies. Designed for 2.00 mm pitch applications, this set of 20 natural-colored rectangular housings features a secure locking structure and is compatible with wire sizes from AWG #26 to #22. Ideal for PCB applications, it meets RoHS standards and offers high insulation resistance and voltage withstand capabilities. Get yours today for dependable performance in all your electronic projects.
Order your JST Series PUDP20VS connector housing today and ensure your electronic projects benefit from high reliability and secure connections.
Frequently Asked Questions
Where can I buy JST PUDP20VS?
You can click on the BUY or RFQ button to purchase PUDP20VS from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part PUDP20VS?
You can download the PUDP20VS datasheet or visit the JST website for support.
Who is the manufacturer of PUDP20VS?
JST
