JST RF08 Crimp Connector Housing
This 8-position connector housing with a 2.54mm pitch is suitable for crimp connections, supporting wire gauges from AWG 30 to 24. Made from black PBT, it features a top entry type design with a polarizing key to prevent misinsertion. The connector has a rated voltage of 250V AC/DC and a current rating of 2A, with environmental resistance up to 105°C and an insulation resistance of 1,000MΩ. Its space-saving high-density layout makes it ideal for compact circuit designs in office and automation equipment.
JST RF08 Crimp Connector Housing Specifications:
- Number of circuits: 8
- Pitch: 2.54mm
- Material: PBT, UL94V-0, black
- Rated voltage: 250V AC/DC
- Current rating: 2A
- Applicable wire: AWG #30 to #24
- Temperature range: -55°C to +105°C (gold-plated), -55°C to +85°C (tin-plated)
- Contact resistance: Initial value/15mΩ max, after environmental testing/30mΩ @ max
- Insulation resistance: 1,000MΩ min
- Withstanding voltage: 1,500V AC/minute
- Dimensions: Not specified in extracted data
- RoHS compliant
- Housing type: Top entry
- Polarizing key included to prevent misinsertion
Buy the JST Series 2.54mm Pitch Crimp Connector Housing: RF08
Order the JST RF08 connector housing online today to ensure high-quality, reliable connections for your electrical projects. This 8-position, 2.54mm pitch connector features a durable black PBT housing, supporting wires from AWG 30 to 24. Its space-efficient design includes a polarizing key to prevent misalignment, making it perfect for tight spaces in automation and office systems. Enjoy fast shipping and seamless online purchasing to enhance your circuit assemblies conveniently.
Buy JST RF08 black crimp connector housing now and experience reliable connections with space-saving high-density design, ideal for compact electronic devices.
Frequently Asked Questions
Where can I buy JST RF08?
You can click on the BUY or RFQ button to purchase RF08 from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part RF08?
You can download the RF08 datasheet or visit the JST website for support.
Who is the manufacturer of RF08?
JST
