JST RSFP7V RSF Series Connector
The RSF Series header connector features seven positions with a 5.0mm pitch, securely locking female contacts, and offers easy insertion and removal. Designed for reliable connection, it accommodates wires from 14 to 22 AWG, ensuring stable contact performance even under high current loads. The connector's robust housing allows for customizable keying options, with cavity blocking plugs and various color choices. Compliant with recognized standards, it provides excellent insulation resistance, withstands high voltages, and is suitable for diverse electronic applications requiring secure, stable, and versatile wire-to-board connections.
JST RSFP7V RSF Series Connector Specifications:
- Current rating: 20A AC, DC max.
- Voltage rating: 250V AC/DC max.
- Temperature range: -40°C to +105°C
- Contact resistance: Initial 3mΩ max., After environmental testing 6mΩ max.
- Insulation resistance: ≥ 1,000MΩ
- Withstanding voltage: 2,000V AC/minute
- Applicable wire: 14-22 AWG
- Material: Nylon 66, UL94V-0, natural color
- Housing options include key removal and cavity blocking
- Compatible with NEMA and PC mounted tabs
- Connector dimensions: Y max. 12.6mm (0.496in), Max. length 7.4mm (0.291in), width varies with model
- Designed for secure locking with easy mating and un mating capabilities
Buy the JST Series RSF: 7-Position Wire Connector and Locking Header
Secure your electronic wiring with the JST RSF series 7-position connector. Featuring a 5.0mm pitch, easy locking mechanism, and compatibility with 14-22 AWG wires, this connector provides stable contacts and high durability. Designed with versatile housing options, including key removal and cavity blocking, it meets international standards for insulation and voltage resistance. Perfect for industry, automation, or PCB applications, order online now for fast delivery and project-ready quality, ensuring reliable, safe, and efficient connections in your electronic assemblies.
Order your JST Series RSF 7-Position Wire Connector today and ensure secure, reliable connections for your electronic projects.
Frequently Asked Questions
Where can I buy JST RSFP7V?
You can click on the BUY or RFQ button to purchase RSFP7V from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part RSFP7V?
You can download the RSFP7V datasheet or visit the JST website for support.
Who is the manufacturer of RSFP7V?
JST
