JST S7BJLRLFSN connector header
This JL Series 7-position connector header features a secure lock mechanism, 2.5mm pitch, side entry design, and is rated for 250V. Constructed with phosphorus bronze contacts tin-plated for corrosion resistance and housed in durable PA 66 material. Suitable for high-density board-to-board connections in electronic equipment requiring vibration resistance, it ensures reliable performance with reinforced pins for added PCB mounting durability. The connector’s blue color aids quick identification, making it ideal for precise, durable electrical connections in various industrial applications.
JST S7BJLRLFSN connector header Specifications:
- Current rating: 3A AC, DC
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Contact material: Phosphor bronze, tin-plated
- Housing material: PA 66, UL94V-0, blue color
- Reinforcing pins: Brass, copper-undercoated, tin-plated
- Number of circuits: 7
- Connector type: Header with secure lock mechanism
- Pitch: 2.5mm
- Applicable PC board thickness: 1.6mm
- RoHS compliant
- Rated for high-density mounting and vibration resistance
Buy the Buy JST JL Connector Part Number S7BJLRLFSN Online
Experience the reliability of the JST JL Series connector header with secure lock, 2.5mm pitch, and rated for 250V. Designed for high-density and vibration-resistant applications, its phosphor bronze contacts and durable PA 66 housing ensure long-term performance. The blue color makes identification easy, while reinforced pins add durability for PCB mounting. Ideal for electronic equipment requiring secure, vibration-proof connections, this connector provides robust, stable electrical contact in demanding industrial and commercial environments. Purchase online now for fast and secure delivery.
Get JST JL Connector S7BJLRLFSN today—built for high-density connections and long-lasting durability in electronic assemblies.
Frequently Asked Questions
Where can I buy JST S7BJLRLFSN?
You can click on the BUY or RFQ button to purchase S7BJLRLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part S7BJLRLFSN?
You can download the S7BJLRLFSN datasheet or visit the JST website for support.
Who is the manufacturer of S7BJLRLFSN?
JST
