JST SHR08VS connector housing
This 1.0mm pitch connector housing from the SH Series offers a reliable, compact design for easy connection in free hanging applications. Made of UL94V-0 flame-retardant black plastic, it features 8 positions, with no protrusions for secure fitment. Compatible with crimp contacts and designed for high-performance connections, the housing ensures low contact resistance and durability under various environmental conditions. Suitable for use in electronic devices, automation systems, and industrial equipment requiring space-efficient and dependable interconnections.
JST SHR08VS connector housing Specifications:
- Contact Material: Copper alloy, tin-plated (reflow treatment)
- Housing Material: PBT, UL94V-0, natural (white)
- Number of Positions: 8
- Pitch: 1.0mm
- Temperature Range: -25°C to +85°C
- Voltage Rating: 50V AC/DC
- Current Rating: 1.0A AC/DC (AWG #28)
- Contact Resistance: Initial/20mΩ max, Environmental/40mΩ max
- Insulation Resistance: 100MΩ min
- Withstanding Voltage: 500V AC/minute
- Applicable Wire: AWG #32 to #28, Insulation O.D. 0.4 to 0.8mm
- RoHS Compliant
- Housing Flammability: UL 94V-0
- Assembly Layout: Top entry and side entry types available
Buy the JST SH Series Connectors – Reliable 1.0mm Pitch for Industrial Applications
Purchase the JST SH08VS connector housing online today to enjoy high-quality, space-saving electronic interconnections. Expertly designed for automatic assembly, it features a 1.0mm pitch, 8 positions, and UL94V-0 flame-retardant material for safety and durability. Compatible with crimp contacts, it offers reliable electrical performance in a variety of industrial applications. Easy to handle and install, this connector housing guarantees secure fitting and long-term stability for your electronic devices, automation systems, and PCB layouts.
Order your JST Series SH08VS connector housing today and ensure dependable, space-efficient connections for your electronic projects and industrial systems.
Frequently Asked Questions
Where can I buy JST SHR08VS?
You can click on the BUY or RFQ button to purchase SHR08VS from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part SHR08VS?
You can download the SHR08VS datasheet or visit the JST website for support.
Who is the manufacturer of SHR08VS?
JST
