JST SM05BGHSGBTBLFSN SMT Header
This surface-mount header is designed for electronic circuits using SMT technology, offering a sturdy construction for reliable electrical connections and easy assembly. Its robust design and precise dimensions ensure secure mating with compatible connectors, making it suitable for small electronics equipment, LCDs, and PDP displays. Crafted from UL94V-0 rated PBT material, it features tin-plated contacts for optimal conductivity and corrosion resistance. The header supports a 1.25mm pitch with a safe voltage rating of 50V and a current of 1.0A, ensuring dependable performance in various electronic applications. Its compatibility with AWG #30 to #26 wire sizes simplifies wiring processes, making it ideal for compact and high-reliability electronic assemblies.
JST SM05BGHSGBTBLFSN SMT Header Specifications:
- Pitch: 1.25mm
- Material: PBT, UL94V-0, natural (ivory)
- Contact Material: Phosphor bronze, tin-plated
- Housing: PBT, UL94V-0, natural
- Solder tab: Brass, copper-undercoated, tin-plated
- Current rating: 1.0A AC/DC (AWG #26)
- Voltage rating: 50V AC/DC
- Temperature range: -25°C to +85°C
- Wire compatibility: AWG #30 to #26, insulation O.D. 0.8-1.0mm
- RoHS compliant
- Dimensions: Length varies with model, typical 5.75mm to 20.00mm, width 2mm, height approximately 2mm
- Suitable for SMT applications, secure locking structure, reliable contact performance
