Johnson-Cinch Connectivity Solutions 1080901001 Banana Jack
The 108-0901-001 is a durable red banana jack with an insulated solder terminal, compatible with standard 0.175-inch banana plugs. Made from UL-approved nylon 6/6, it offers a keyed mounting with double flats for secure installation and accepts wire gauges up to 16 AWG. The formed brass contact features bright tin finish, providing excellent conductivity with a resistance of maximum 0.010 ohms. Suitable for test equipment, it withstands up to 7000 V minimum breakdown voltage, making it ideal for reliable electrical connections in various industrial and measurement applications.
Johnson-Cinch Connectivity Solutions 1080901001 Banana Jack Specifications:
- Contact Material: Formed brass per QQ-B-626D
- Finish: Bright tin
- Body Material: Nylon 6/6 per ASTM D4066
- Hardware: Nickel plated nut (unassembled)
- Body Thread Stripping Torque: 6.0 Ib. in. (7kg. cm.)
- Panel Thickness: Up to 0.343 inches (8.80 mm)
- Current Rating: 15 amps
- Breakdown Voltage: 7000 V minimum
- Contact Resistance: 0.010 ohms maximum
- Contact-To-Panel Capacitance: 2.4 pF
- Across Flats: 0.175 inches (4.44 mm)
- UL Approved Nylon Material: Self extinguishing
- Mounting: Keyed with double flats
- Accepts Wire: Up to 16 gauge AWG
- Features: Secure keyed mounting, bright tin plating, insulation for safety, compatible with standard banana plugs
- Application: Test and measurement, industrial wiring, electrical testing
Buy the Cinch Series Banana Jack Insulated Solder Terminal Part Number 1080901001
Order the Cinch Banana Jack today for secure, reliable electrical connections suitable for test, measurement, and industrial testing environments. Featuring an insulated solder terminal and keyed mounting, it ensures safety and stability. Made from UL-approved nylon with bright tin-plated brass contacts, it offers low contact resistance and high voltage breakdown strength. Suitable for wires up to 16 AWG, this banana jack delivers consistent performance under demanding conditions. Perfect for technicians and engineers seeking dependable connectivity solutions with easy installation — buy now to enhance your tools and testing gear.
Buy Cinch Banana Jack now and experience unmatched reliability and performance in electrical connections and testing setups.
Frequently Asked Questions
Where can I buy Johnson-Cinch Connectivity Solutions 1080901001?
You can click on the BUY or RFQ button to purchase 1080901001 from an authorized Johnson-Cinch Connectivity Solutions distributor.
How do I troubleshoot issues or seek technical support for part 1080901001?
You can download the 1080901001 datasheet or visit the Johnson-Cinch Connectivity Solutions website for support.
Who is the manufacturer of 1080901001?
Johnson-Cinch Connectivity Solutions
