KEMET A72QQ2220AA02K Polypropylene Film Capacitor
The A72QQ2220AA02K is a high-quality film/foil polypropylene capacitor designed for general-purpose applications, offering reliable performance with a capacitance of 0.022 uF and a voltage rating of 400 VAC / 1000 VDC. It features axial wire leads, RoHS compliance, and a maximum size of 28 mm in length. Rated for temperatures up to 85°C, it boasts excellent insulation resistance of 100 GOhms and low dissipation factor, making it ideal for power supply filtering and AC/DC applications requiring high dielectric strength and stability.
KEMET A72QQ2220AA02K Polypropylene Film Capacitor Specifications:
- Capacitance: 0.022 uF
- Capacitance Tolerance: 10%
- Voltage AC: 400 VAC
- Voltage DC: 1000 VDC (105°C), 750 VDC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dimensions: Length 28mm, maximum; Diameter 0.8mm, ±0.05mm
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.05% at 10kHz, 0.1% at 100kHz
- Lead Type: Wire Leads
- RoHS Compliant
- Operating Frequencies: Up to 10kHz
- Dielectric Material: Film/Foil Polypropylene
- Inductance: 28 nH
- Packaging: Bulk, Bag
- Maximum dV/dt: 5000 V/μs
Buy the KEMET A72QQ2220AA02K – Reliable Polypropylene Capacitor for Industrial Applications
Purchase the KEMET polypropylene film capacitor A72QQ2220AA02K online and enjoy dependable quality for industrial and power supply applications. With a capacitance of 0.022 uF, 400VAC / 1000VDC ratings, axial wire leads, and RoHS compliance, this capacitor is ideal for filtering, power electronics, and industrial systems requiring high dielectric strength. Rated for working temperatures up to 85°C, it provides excellent insulation resistance of 100 GOhms and low dissipation factor. Buy online now for swift delivery and optimal performance in your electronic projects.
Order your KEMET Series A72QQ2220AA02K polypropylene capacitor today and ensure reliable performance for your power and industrial projects.
Frequently Asked Questions
Where can I buy KEMET A72QQ2220AA02K?
You can click on the BUY or RFQ button to purchase A72QQ2220AA02K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A72QQ2220AA02K?
You can download the A72QQ2220AA02K datasheet or visit the KEMET website for support.
Who is the manufacturer of A72QQ2220AA02K?
KEMET
