KEMET A750BG277M0JAAE020 Polymer Aluminum Capacitor
The KEMET A750BG277M0JAAE020 is a high-quality polymer aluminum capacitor with a capacitance of 270 microfarads and a voltage rating of 6.3V DC. Designed for reliable use in broad temperature ranges from -55°C to +105°C, it features wire leads for easy integration. Its compact dimensions include a 5mm diameter, 7mm length, and 2mm lead spacing, making it suitable for space-constrained applications. The capacitor offers 20% capacitance tolerance, low leakage current, and high ripple current capacity, ensuring long-lasting performance in electronic circuits.
KEMET A750BG277M0JAAE020 Polymer Aluminum Capacitor Specifications:
- Capacitance: 270 uF
- Capacitance Tolerance: 20%
- Voltage DC: 6.3 VDC, 7.2 VDC (Surge)
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Diameter 5mm +/-0.5mm, Length 7mm +/-1mm, Lead Spacing 2mm +/-0.5mm
- Leakage Current: 340.2 uA (2min at 20°C)
- Ripple Current: 3100 mAmps (at 100kHz, 105°C)
- Dissipation Factor: 12% at 120Hz 20°C
- Resistance: 20 mOhms (at 100kHz 20°C)
- Lifespan: 2000 hours at rated conditions with specific parameters
Buy the Buy KEMET Polymer Aluminum Part Number A750BG277M0JAAE020 Online
Enhance your electronic designs with the KEMET polymer aluminum capacitor, offering 270 microfarads at 6.3 volts. It operates efficiently from -55°C to +105°C and features wire leads for easy connection. Its small size makes it ideal for space-sensitive circuits while providing high ripple current capacity and low leakage, ensuring longevity and reliability. Perfect for power supplies, motor drives, and electronic modules, this capacitor guarantees stable performance in demanding environments. Purchase online now for fast delivery and trusted quality.
Get KEMET A750BG277M0JAAE020 today—engineered for high performance and durability in compact electronic applications.
Frequently Asked Questions
Where can I buy KEMET A750BG277M0JAAE020?
You can click on the BUY or RFQ button to purchase A750BG277M0JAAE020 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A750BG277M0JAAE020?
You can download the A750BG277M0JAAE020 datasheet or visit the KEMET website for support.
Who is the manufacturer of A750BG277M0JAAE020?
KEMET
