KEMET A758EK477M0JAAE015 Aluminum Polymer Capacitor
The KEMET A758 aluminum polymer capacitor offers reliable performance with a capacitance of 470 uF and a tolerance of 20%. Rated for -55°C to +105°C and a voltage of 6.3 VDC, this high-quality component features wire leads, low equivalent series resistance, and excellent life durability of over 5000 hours at 105°C. Suitable for various electronic applications, it ensures stability, low leakage, and consistent ripple current handling. The capacitor's compact dimensions and RoHS compliance make it ideal for space-constrained industrial and consumer electronics requiring dependable power management.
KEMET A758EK477M0JAAE015 Aluminum Polymer Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 6.3 VDC, 7.2 VDC (Surge)
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Diameter 6.3mm ±0.5mm, Length 8mm ±1mm, Lead Spacing 2.5mm ±0.5mm
- Leakage Current: 444.15 uA (2 min, 20°C)
- Ripple Current: 3100 mA (100kHz, 105°C)
- Resistance: 15 mOhms (100kHz, 20°C)
- Dissipation Factor: 10% at 120Hz, 20°C
- Lifespan: 5000 hours at 105°C with ±20% capacitance variation
Buy the KEMET A758EK477M0JAAE015 – Reliable Aluminum Polymer Capacitor for Industrial Applications
Purchase the KEMET aluminum polymer capacitor online now and experience reliable performance with 470 uF capacity, 6.3 VDC rating, and temperature stability from -55°C to +105°C. Designed with wire leads, RoHS compliance, and low resistance, this capacitor is ideal for industrial and electronic applications requiring long-lasting, stable power management. Available in bulk packaging, it ensures easy integration into your designs, providing consistent ripple current handling and low leakage. Secure your stock today for high-quality electronic performance.
Order your KEMET Series A758 aluminum polymer capacitor today and enhance your electronic projects with dependable, high-performance power storage components.
Frequently Asked Questions
Where can I buy KEMET A758EK477M0JAAE015?
You can click on the BUY or RFQ button to purchase A758EK477M0JAAE015 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A758EK477M0JAAE015?
You can download the A758EK477M0JAAE015 datasheet or visit the KEMET website for support.
Who is the manufacturer of A758EK477M0JAAE015?
KEMET
