KEMET A758KK687M0EAAE016 Polymer Aluminum Capacitor
The polymer aluminum capacitor A758 series features a capacitance of 680 uF with a 20% tolerance, designed for high reliability in compact circuits. Operating between -55°C and +105°C, it supports voltages of 2.5 VDC and surge up to 2.9 VDC. Its low ESR of 16 mOhms at 100kHz and ripple current of 4100 mA make it suitable for demanding applications. With lead wire configuration, dimensions of approximately 8mm in diameter and 8mm in length, and a lead spacing of 3.5mm, this RoHS-compliant capacitor offers stability, efficiency, and durability for power management and electronic device circuits.
KEMET A758KK687M0EAAE016 Polymer Aluminum Capacitor Specifications:
- Capacitance: 680 uF
- Capacitance Tolerance: 20%
- Voltage DC: 2.5 VDC, surge up to 2.9 VDC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Life Expectancy: 5000 hours at maximum operating conditions
- Leakage Current: 255 uA (2 minutes at 20°C)
- Dissipation Factor: 10% at 120Hz, 20°C
- Equivalent Series Resistance: 16 mOhms at 100kHz, 20°C
- Ripple Current: 4100 mA at 100kHz, 105°C
- Dimensions: Diameter 8mm ±0.5mm, Length 8mm ±1mm, Lead Spacing 3.5mm ±0.5mm
- Lead Type: Wire Leads
- RoHS Compliant: Yes
- Packaging: Bulk, Bag, Quantity: 500
Buy the KEMET Series A758 Polymer Aluminum Capacitor: A758KK687M0EAAE016
Secure your electronic projects with the KEMET Polymer Aluminum Capacitor from the A758 series. With a capacitance of 680 uF and a voltage rating of 2.5 VDC, this capacitor ensures reliable performance across a wide temperature range of -55°C to +105°C. Its low resistance and high ripple current capacity make it perfect for power supply filtering, energy storage, and demanding electronic applications. Designed with wire leads and RoHS compliance, this durable component offers excellent stability, longevity, and easy installation for manufacturers and DIY enthusiasts alike.
Get KEMET A758KK687M0EAAE016 today—built for power stability and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET A758KK687M0EAAE016?
You can click on the BUY or RFQ button to purchase A758KK687M0EAAE016 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A758KK687M0EAAE016?
You can download the A758KK687M0EAAE016 datasheet or visit the KEMET website for support.
Who is the manufacturer of A758KK687M0EAAE016?
KEMET
