KEMET A759KK225M2EAAE685 Polymer Aluminum Capacitor
The KEMET A759KK225M2EAAE685 is a polymer aluminum electrolytic capacitor designed for applications requiring high capacitance density and long life. It offers excellent performance characteristics, including a wide operating temperature range (-55°C to +125°C) and low ESR. This capacitor is ideal for use in power supplies, DC-DC converters, and other demanding electronic circuits where stable and reliable capacitance is crucial. Its polymer aluminum construction ensures extended lifespan and improved performance compared to traditional electrolytic capacitors. The capacitor is RoHS compliant, aligning with environmental regulations and promoting sustainable practices.
KEMET A759KK225M2EAAE685 Polymer Aluminum Capacitor Specifications:
- Series: A759
- Dielectric: Polymer Aluminum
- Description: Single Ended, Polymer Aluminum
- Capacitance: 2.2 uF
- Capacitance Tolerance: 20%
- Voltage DC: 250 VDC, 287.5 VDC (Surge)
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Life: 2000 Hrs (+/-20% Initial Capacitance, 1.5x DF MAX, Leakage Within Limit)
- Dissipation Factor: 12% 120Hz 20C
- Resistance: 685 mOhms (100kHz 20C)
- Ripple Current: 210 mAmps (100kHz 105C), 70 mAmps(100kHz 125C)
- Leakage Current: 120 uA (2min 20°C)
- Lead: Wire Leads
- AEC-Q200: No
- Halogen Free: Yes
- D: 8mm +/-0.5mm
- L: 8mm +/-1mm
- S: 3.5mm +/-0.5mm
- LL Negative: 15mm MIN
- LL Positive: 19mm MIN
- F: 0.6mm +/-0.05mm
- Packaging: Bulk, Bag
- Packaging Quantity: 500
Buy the A759KK225M2EAAE685 KEMET Polymer Aluminum Capacitor | myMectronic
Purchase the KEMET A759KK225M2EAAE685 Polymer Aluminum Capacitor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy KEMET A759KK225M2EAAE685?
You can click on the BUY or RFQ button to purchase A759KK225M2EAAE685 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A759KK225M2EAAE685?
You can download the A759KK225M2EAAE685 datasheet or visit the KEMET website for support.
Who is the manufacturer of A759KK225M2EAAE685?
KEMET
