KEMET A759KS476M1JAAE068 Polymer Aluminum Capacitor
The KEMET A759KS476M1JAAE068 is a polymer aluminum electrolytic capacitor designed for applications requiring high capacitance and voltage stability. It boasts a capacitance of 47µF, a voltage rating of 63VDC, and an operating temperature range from -55°C to +125°C. The capacitor's polymer aluminum construction provides low ESR and high ripple current handling capabilities, making it ideal for power supplies, DC-DC converters, and other demanding applications. Its RoHS compliance ensures environmentally friendly operation. KEMET disclaims any warranty concerning suitability for a specific customer application.
KEMET A759KS476M1JAAE068 Polymer Aluminum Capacitor Specifications:
- Series: A759
- Dielectric: Polymer Aluminum
- Description: Single Ended, Polymer Aluminum
- Capacitance: 47 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC, 72.45 VDC (Surge)
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Life: 2000 Hrs (+/-20% Initial Capacitance, 1.5x DF MAX, Leakage Within Limit)
- Dissipation Factor: 12% 120Hz 20C
- Resistance: 68 mOhms (100kHz 20C)
- Ripple Current: 1630 mAmps (100kHz 105C), 950 mAmps(100kHz 125C)
- Leakage Current: 444.15 uA (2min 20°C)
- D: 8mm +/-0.5mm
- L: 12mm +/-1mm
- S: 3.5mm +/-0.5mm
- LL Negative: 15mm MIN
- LL Positive: 19mm MIN
- F: 0.6mm +/-0.05mm
- Packaging: Bulk, Bag
- Packaging Quantity: 500
- AEC-Q200: No
- Halogen Free: Yes
- Lead: Wire Leads
