KEMET A759PY687M1HAAE026 Polymer Aluminum Capacitor
The KEMET A759PY687M1HAAE026 polymer aluminum capacitor is designed for a wide range of applications including consumer electronics, power supplies, and LED lighting. Its polymer dielectric provides high capacitance density, low ESR, and excellent frequency characteristics. With a rated temperature of 125°C and a life of 2000 hours, this capacitor ensures reliable performance in demanding environments. The capacitor's robust construction and high voltage rating make it suitable for various industrial and commercial applications.
KEMET A759PY687M1HAAE026 Polymer Aluminum Capacitor Specifications:
- Series: A759
- Dielectric: Polymer Aluminum
- Description: Single Ended, Polymer Aluminum
- Capacitance: 680 uF
- Capacitance Tolerance: 20%
- Voltage DC: 50 VDC, 57.5 VDC (Surge)
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Life: 2000 Hrs (+/-20% Initial Capacitance, 1.5x DF MAX, Leakage Within Limit)
- Dissipation Factor: 12% 120Hz 20C
- Resistance: 26 mOhms (100kHz 20C)
- Ripple Current: 6520 mAmps (100kHz 105C), 3800 mAmps(100kHz 125C)
- Leakage Current: 5100 uA (2min 20°C)
- D: 13mm +/-0.5mm
- L: 20mm +/-2mm
- S: 5mm +/-0.5mm
- LL Negative: 15mm MIN
- LL Positive: 19mm MIN
- F: 0.6mm +/-0.05mm
- Packaging: Bulk, Bag
