KEMET A765KN158M0ELAE010 Polymer Aluminum Capacitor
The KEMET A765KN158M0ELAE010 is a polymer aluminum capacitor designed for a wide range of industrial applications requiring high capacitance and voltage stability. Featuring a capacitance of 1500uF and a voltage rating of 2.5VDC, this capacitor offers excellent performance in demanding environments. Its surface mount design and operating temperature range of -55°C to +105°C make it ideal for applications such as power supplies, filtering, and energy storage.
KEMET A765KN158M0ELAE010 Polymer Aluminum Capacitor Specifications:
- Series: A765
- Dielectric: Polymer Aluminum
- Style: SMD Can
- Description: Surface Mount, Polymer Aluminum
- Capacitance: 1,500 uF
- Capacitance Tolerance: 20%
- Voltage DC: 2.5 VDC, 2.9 VDC (Surge)
- Temperature Range: -55/+105°C
- Rated Temperature: 105°C
- Life: 2000 Hrs
- Resistance: 10 mOhms (100kHz 20C)
- ESR/Impedance at 100kHz: 10 mOhms
- Ripple Current: 3400 mAmps (100kHz 105C)
- Leakage Current: 750 uA (2min 20°C)
- High Temperature Solder: No
- Packaging: T&R, 380mm
- Packaging Quantity: 500
Buy the A765KN158M0ELAE010 KEMET Polymer Aluminum Capacitor | myMectronic
Purchase the KEMET A765KN158M0ELAE010 Polymer Aluminum Capacitor securely and reliably through our online store.
Buy Now
Frequently Asked Questions
Where can I buy KEMET A765KN158M0ELAE010?
You can click on the BUY or RFQ button to purchase A765KN158M0ELAE010 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A765KN158M0ELAE010?
You can download the A765KN158M0ELAE010 datasheet or visit the KEMET website for support.
Who is the manufacturer of A765KN158M0ELAE010?
KEMET
