KEMET ALC70A153CD040 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor ALC70A153CD040 offers a capacitance of 15,000 uF with a 20% tolerance, rated at 40 VDC. Designed for reliable performance in various electronic applications, it features a Snap-In design suitable for PCB mounting, with dimensions of 30mm diameter and 40mm length. Operating efficiently within -40°C to +85°C, it provides a ripple current of up to 8.342A at 85°C and has a lifespan of approximately 6,411 hours at rated conditions. Its RoHS and halogen-free compliance make it an eco-friendly component with excellent leakage and resistance characteristics.
KEMET ALC70A153CD040 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 15,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 40 VDC, 46 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 30mm, Length 40mm
- Leakage Current: 3600 uA (5min 20°C)
- Ripple Current: 6.411 A (100Hz 85°C), 8.342 A (10kHz 85°C)
- Resistance: 40-38 mΩ (100Hz 20°C)
- Shelf Life: 156 Weeks
- RoHS Compliant: Yes
- Halogen Free: Yes
- Weight: 50g
Buy the KEMET ALC70A153CD040 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Secure your electronic projects with the high-quality aluminum electrolytic capacitor designed for durability and consistent performance. Featuring a capacitance of 15,000 uF at 40 VDC, this component is ideal for power supply filtering, energy storage, and smoothing applications. Its robust construction ensures long service life, with excellent ripple current handling and resistance features. RoHS compliant and halogen-free, it supports eco-friendly manufacturing. Easy to install with Snap-In design, this capacitor guarantees reliable operation across wide temperature ranges, making it an excellent choice for industrial and commercial electronic systems.
Buy KEMET ALC70A153CD040 now and experience unmatched reliability and performance in your electronic projects.
Frequently Asked Questions
Where can I buy KEMET ALC70A153CD040?
You can click on the BUY or RFQ button to purchase ALC70A153CD040 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC70A153CD040?
You can download the ALC70A153CD040 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC70A153CD040?
KEMET
