KEMET ALC70A221CD450 Electrolytic Capacitor
The aluminum electrolytic capacitor with a capacitance of 220 uF and a voltage rating of 450 VDC is designed for high-voltage applications. It features a snap-in design, RoHS compliance, and halogen-free construction, making it suitable for industrial and electronic power equipment. Rated for a temperature range of -40°C to +85°C, it offers a ripple current capacity of 15 Amps at 85°C, with a lifespan of up to 21,000 hours at rated conditions. Its compact dimensions include a 30mm diameter and 40mm length, ensuring easy integration into various circuit layouts.
KEMET ALC70A221CD450 Electrolytic Capacitor Specifications:
- Capacitance: 220 uF
- Capacitance Tolerance: 20%
- Voltage DC: 450 VDC, 495 VDC (Surge)
- Dimensions: Diameter 30mm, Length 40mm
- Rated Temperature: -40/+85°C
- Temperature Range: -40°C to +85°C
- Life: 21,000 hours at 85°C (Rated Voltage)
- Ripple Current: 15 Amps at 10kHz, 85°C
- Leakage Current: 594 microamps (5 min at 20°C)
- Resistance: 28 mOhms (100Hz, 20°C), 3.84 mOhms (10kHz, 20°C)
- RoHS Compliant: Yes
- Halogen Free: Yes
- Weight: 50g
- Shelf Life: 156 Weeks
- Leakage Current: 594 μA at 20°C for 5 minutes
Buy the Buy YAGEO Capacitor Part Number ALC70A221CD450 Online
Purchase the YAGEO electrolytic capacitor ALC70A221CD450 today and ensure reliable high-voltage performance in your electronic and industrial applications. This robust capacitor features a capacitance of 220 microfarads, voltage rating of 450 volts, and a temperature range from -40°C to +85°C. It’s RoHS compliant and halogen-free, making it suitable for environmentally conscious projects. With a lifespan of over 21,000 hours at rated conditions and a ripple current capacity of 15 amps at 85°C, this capacitor guarantees durability, efficiency, and consistent operation for power supply systems and electronic devices.
Get YAGEO ALC70A221CD450 today—designed for high-voltage power supply applications and long-lasting performance.
Frequently Asked Questions
Where can I buy KEMET ALC70A221CD450?
You can click on the BUY or RFQ button to purchase ALC70A221CD450 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC70A221CD450?
You can download the ALC70A221CD450 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC70A221CD450?
KEMET
