KEMET ALC70A471DC350 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor series ALC70 offers a reliable solution for high-voltage applications with 470 uF capacitance, 350 VDC working voltage, and a temperature range of -40/+85°C. Designed with snap-in mounting, it features a low equivalent series resistance and a long shelf life of 156 weeks. Suitable for power supplies, filtering, and energy storage, this rugged capacitor is halogen-free, RoHS compliant, and weighs 60 grams, making it ideal for demanding electrical environments.
KEMET ALC70A471DC350 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 350 VDC, 385 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 35mm +1mm, Length approximately 50mm (including sleeving)
- Sleeving: Yes
- Shelf Life: 156 Weeks
- Leakage Current: 987 uA (5 min at 20°C)
- Ripple Current at 85°C: 2.246 Amps at 100Hz, 5.259 Amps at 10kHz
- Equivalent Series Resistance: 3015 mOhms (100Hz, 20°C), 158.3 mOhms (10kHz, 20°C)
Buy the KEMET Series ALC70 Aluminum Electrolytic Capacitor: ALC70A471DC350
Purchase the KEMET Series ALC70 aluminum electrolytic capacitor online for your power supply, filtering, and energy storage needs. With a capacitance of 470 uF, 350 VDC rating, and operating temperature range of -40 to +85°C, this high-quality component ensures reliable and long-lasting performance. Its snap-in design simplifies installation, while halogen-free and RoHS compliance meet safety standards. Weighing 60 grams, it offers excellent ripple current capacity and low ESL, making it ideal for demanding electrical projects. Buy now for superior durability and efficiency.
Order your KEMET Series ALC70 aluminum electrolytic capacitor today and ensure reliable performance in high-voltage power applications.
