KEMET ALF70C561DF450 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor ALF70C561DF450 features a 560 microfarad capacitance with a 20% tolerance and a 450 VDC voltage rating, suitable for various industrial applications. It is a press-fit style component designed for PCB mounting, RoHS compliant, and halogen-free. The capacitor operates effectively within a temperature range of -40°C to +85°C, with a rated temperature of 85°C. With dimensions of approximately 36mm in diameter and 50mm in length, it weighs around 80g. The device offers low equivalent series resistance (ESR) and high ripple current capacity, making it durable and reliable for long-term operation in demanding environments.
KEMET ALF70C561DF450 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 560 uF
- Capacitance Tolerance: 20%
- Voltage DC: 450 VDC, 495 VDC (Surge)
- Dimensions: D 36mm +1mm, L 50mm ±2mm
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Shelf Life: 156 Weeks
- Ripple Current at 85°C: 2.799 Amps (100Hz), 6.452 A (10kHz)
- Leakage Current: 1512 uA (5min 20°C)
- Resistance: 228 mOhms (100Hz 20°C), 143.1 mOhms (10kHz 20°C)
- RoHS Compliant: Yes
- Halogen Free: Yes
- Packaging: Bulk, 15000 hrs at rated voltage and temperature
- Lead: 4 Pin Press-Fit
- Component Weight: 80g
Buy the KEMET ALF70C561DF450 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Experience the reliable performance of the aluminum electrolytic capacitor with 560 microfarad capacitance and 450VDC voltage rating. Designed for demanding industrial applications, this press-fit component offers stability and high ripple current capacity across a temperature range of -40°C to +85°C. Its low ESR and long shelf life make it ideal for power supplies, motor drives, and energy storage solutions. Easy to install, RoHS compliant, halogen-free, and available in bulk packaging, this capacitor ensures durability and consistent performance in critical electronic systems.
Get KEMET ALF70C561DF450 today—built for high-voltage power supply projects and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET ALF70C561DF450?
You can click on the BUY or RFQ button to purchase ALF70C561DF450 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF70C561DF450?
You can download the ALF70C561DF450 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF70C561DF450?
KEMET
