KEMET ALS30A101DA500 Aluminum Electrolytic Capacitor
The ALS30A101DA500 is a screw terminal aluminum electrolytic capacitor with a capacitance of 100 microfarads, tolerance of 20%, and a voltage rating of 500 VDC. Designed for reliable performance, it operates efficiently within the temperature range of -40°C to +85°C, making it suitable for high-voltage applications. This passive electronic component features durable aluminum construction, a rated lifespan of up to 22,000 hours under rated voltage at 85°C, and is RoHS compliant. Its compact dimensions and screw terminal mounting facilitate easy integration into various electronic and industrial systems.
KEMET ALS30A101DA500 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 100 uF
- Capacitance Tolerance: 20%
- Voltage DC: 500 VDC, 550 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: D 36mm +/-1mm, L 52mm +/-2mm, T 7.1mm +/-0.5mm, s 12.8mm +/-0.5mm, DT 8mm +/-0.5mm, ne 58.5mm +/-1mm, TD 10mm MIN, Vv 8mm NOM
- Material: Aluminum electrolytic
- Mounting: Screw terminal (M8x12)
- RoHS: Yes
- Shelf Life: 156 Weeks
- Leakage Current: 300 uA (5 min at 20°C)
- Ripple Current: 1.6 Amps (100Hz, 85°C), 2.9 Amps (10kHz, 85°C)
- Resistance: 1385 mOhms (100Hz 20°C), 847 mOhms (10kHz 20°C)
Buy the Buy KEMET Aluminum Electrolytic Part Number ALS30A101DA500 Online
Enhance your electronic projects with the high-performance KEMET Aluminum Electrolytic Capacitor. Designed for reliable operation at 500 VDC and temperatures from -40°C to +85°C, it features a screw terminal for easy mounting and durable aluminum construction. With a capacitance of 100 microfarads and a lifespan of up to 22,000 hours at rated voltage, this capacitor ensures longevity and stability in your circuit. Order online now for fast delivery and confident installation in industrial and high-voltage applications.
Get KEMET ALS30A101DA500 today—built for high-voltage applications and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET ALS30A101DA500?
You can click on the BUY or RFQ button to purchase ALS30A101DA500 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS30A101DA500?
You can download the ALS30A101DA500 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS30A101DA500?
KEMET
