KEMET ALS30A682DB063 Electrolytic Capacitor
The ALS30 aluminum electrolytic capacitor features a screw terminal design, 6,800 uF capacitance with 20% tolerance, and a rated voltage of 63 VDC. Suitable for high-reliability applications, it operates within a temperature range of -40°C to +85°C and has a shelf life of 156 weeks. Its dimensions include a diameter of 36mm, length of 62mm, and a minimum height of 10mm, with a weight of 90g. The capacitor is RoHS compliant, with low ESR and leakage current, making it ideal for power filtering and industrial electronics.
KEMET ALS30A682DB063 Electrolytic Capacitor Specifications:
- Capacitance: 6,800 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC, 72.5 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Ripple Current: 8.2 Amps (100Hz 85°C), 9 Amps (10kHz 85°C)
- Leakage Current: 2570 uA at 20°C
- Dimensions: D 36mm ±Lmm, L 62mm ±2mm, T 7.1mm ±0.5mm, s 12.8mm ±0.5mm, ne 67.5mm ±Lmm, DT 8mm ±0.5mm
- Weight: 90g
- RoHS Compliance: Yes
- Packaging: Bulk, Box
- Sleeving: Yes
- Sealing Notes: M8x12, Mounting Clamp V3/H2/2736
- Shelf Life: 156 Weeks
- Application Suitability: Power filtering, industrial electronics, high-reliability circuits
Buy the KEMET ALS30A682DB063 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Secure your power electronics with the KEMET ALS30 aluminum electrolytic capacitor. Featuring 6,800 uF capacity at 63 VDC, operating from -40°C to +85°C, and designed with a screw terminal for easy mounting. Perfect for industrial, power, and electronic applications requiring high reliability and stability. Its RoHS compliance ensures environmentally friendly operation. With a shelf life of 156 weeks, robust construction, low ESR, and leakage current, this capacitor delivers consistent performance. Buy online today to enhance your circuits with dependable, long-lasting components.
Order your KEMET ALS30A682DB063 series capacitors today and ensure your power systems perform reliably with long-lasting aluminum electrolytic solutions.
Frequently Asked Questions
Where can I buy KEMET ALS30A682DB063?
You can click on the BUY or RFQ button to purchase ALS30A682DB063 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS30A682DB063?
You can download the ALS30A682DB063 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS30A682DB063?
KEMET
