KEMET ALS70A113DB063 Aluminum Electrolytic Capacitor
The KEMET ALS70A113DB063 is a robust aluminum electrolytic capacitor designed for demanding industrial applications. With a high capacitance of 11000uF and a voltage rating of 63VDC, this capacitor provides excellent performance in power supplies, filtering circuits, and energy storage systems. Its screw terminal design allows for secure and reliable mounting, while the wide operating temperature range ensures consistent operation in challenging environments. The capacitor's halogen-free construction and RoHS compliance further enhance its suitability for environmentally conscious designs.
KEMET ALS70A113DB063 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS70
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- RoHS: Yes
- AEC-Q200: No
- Halogen Free: Yes
- Component Weight: 90 g
- Shelf Life: 156 Weeks
- Capacitance: 11,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC
- Voltage DC Surge: 72.5 VDC
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Life: 11000 Hrs (Rated Voltage And Ripple Current At 85C), 22000 Hrs(Rated Voltage At 85C)
- Resistance: 43 mOhms (100Hz 20C), 34 mOhms(10kHz 20C)
- Ripple Current: 9.4 Amps (100Hz 85C), 12.7 Amps(10kHz 85C)
- Leakage Current: 4158 uA
- Sleeving: Yes
- Packaging: Tray
- Dimensions D: 36mm +/-1mm
- Dimensions L: 62mm +/-2mm
- Dimensions T: 7.1mm +/-0.5mm
- Dimensions S: 12.8mm +/-0.5mm
- Dimensions DT: 8mm +/-0.5mm
- Dimensions LT: 67.5mm +/-1mm
- Dimensions TD: 10mm MIN
- Dimensions V: 8mm NOM
