KEMET ALS70A203KF100 Aluminum Electrolytic Capacitor
The KEMET ALS70A203KF100 is a high-capacitance aluminum electrolytic capacitor designed for various industrial applications. Featuring a capacitance of 20000uF and a voltage rating of 100VDC, this capacitor is suitable for power supplies, filtering, and energy storage. Its robust construction and wide operating temperature range (-40°C to +85°C) ensure reliable performance in demanding environments. The capacitor is RoHS compliant and includes sleeving for added protection.
KEMET ALS70A203KF100 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS70
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- RoHS: Yes
- AEC-Q200: No
- Halogen Free: Yes
- Component Weight: 300 g
- Dimensions D: 51mm +/-1mm
- Dimensions L: 105mm +/-2mm
- Dimensions T: 5.5mm +/-0.5mm
- Dimensions S: 22.2mm +/-0.5mm
- Dimensions DT: 13mm +/-0.5mm
- Dimensions LT: 110.5mm +/-1mm
- Dimensions TD: 10mm MIN
- Dimensions V: 13.7mm NOM
- Dimensions Z: 10mm NOM
- Capacitance: 20,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 100 VDC
- Voltage DC Surge: 115 VDC
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Life: 18000 Hrs (Rated Voltage And Ripple Current At 85C), 36000 Hrs(Rated Voltage At 85C)
- Resistance: 22 mOhms (100Hz 20C), 19 mOhms(10kHz 20C)
- Ripple Current: 17.2 Amps (100Hz 85C), 20.1 Amps(10kHz 85C)
- Leakage Current: 6000 uA
- Packaging: Tray
- Sleeving: Yes
