KEMET ALS70A243DB040 Aluminum Electrolytic Capacitor
The KEMET ALS70A243DB040 is a high-performance aluminum electrolytic capacitor designed for a variety of industrial applications. With a capacitance of 24000uF and a voltage rating of 40VDC, this capacitor provides reliable power storage and filtering. Its robust construction and wide operating temperature range (-40°C to +85°C) ensure consistent performance in demanding environments. The screw terminal design facilitates easy integration into existing systems. This capacitor is suitable for applications such as power supplies, inverters, and motor drives.
KEMET ALS70A243DB040 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS70
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- RoHS: Yes
- AEC-Q200: No
- Halogen Free: Yes
- Component Weight: 90 g
- Shelf Life: 156 Weeks
- Capacitance: 24000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 40 VDC
- Voltage DC Surge: 46 VDC
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Life: 11000 Hrs (Rated Voltage And Ripple Current At 85C), 22000 Hrs(Rated Voltage At 85C)
- Resistance: 38 mOhms (100Hz 20C), 32 mOhms(10kHz 20C)
- Ripple Current: 10.5 Amps (100Hz 85C), 12.8 Amps(10kHz 85C)
- Leakage Current: 5760 uA
- Sleeving: Yes
- Packaging: Tray
