KEMET ALS70A511DB450 Aluminum Electrolytic Capacitor
The KEMET ALS70A511DB450 is a robust aluminum electrolytic capacitor designed for demanding applications requiring high capacitance and voltage. This capacitor boasts a capacitance of 510µF, a voltage rating of 450VDC, and an operating temperature range of -40°C to +85°C. It is suitable for use in power supplies, filtering circuits, and other applications where reliable performance is critical. The screw terminal design allows for secure and reliable mounting. KEMET’s ALS70 series is known for its durability and long lifespan, making it a dependable choice for industrial and commercial applications.
KEMET ALS70A511DB450 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS70
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- RoHS: Yes
- AEC-Q200: No
- Halogen Free: Yes
- Component Weight: 90 g
- Shelf Life: 156 Weeks
- Capacitance: 510 uF
- Capacitance Tolerance: 20%
- Voltage DC: 450 VDC
- Voltage Surge: 495 VDC
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Life: 11000 Hrs (Rated Voltage And Ripple Current At 85C), 22000 Hrs(Rated Voltage At 85C)
- Resistance: 337 mOhms (100Hz 20C), 212 mOhms(10kHz 20C)
- Ripple Current: 3.2 Amps (100Hz 85C), 6.9 Amps(10kHz 85C)
- Leakage Current: 1377 uA
- Sleeving: Yes
- Packaging: Tray
Buy the ALS70A511DB450 KEMET Aluminum Electrolytic Capacitor | myMectronic
Purchase the KEMET ALS70A511DB450 with confidence and enjoy secure online ordering.
Buy Now
Frequently Asked Questions
Where can I buy KEMET ALS70A511DB450?
You can click on the BUY or RFQ button to purchase ALS70A511DB450 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS70A511DB450?
You can download the ALS70A511DB450 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS70A511DB450?
KEMET
