KEMET C276CC35250AA1J Film Capacitor
The KEMET C27 Series film capacitor features a polypropylene dielectric, with a capacitance of 25 uF and a tolerance of 5%. Rated for 470 VAC, it is designed for motor run applications with a maximum voltage of 15 V. The capacitor has a sonically welded seal, UL-94 VO flammability rating, and RoHS compliance. It measures 40mm in diameter with a length of approximately 40mm, weighs 112g, and operates efficiently within a temperature range of -25°C to +85°C. Suitable for high-voltage, industrial, and motor control applications, it offers reliable performance in demanding environments.
KEMET C276CC35250AA1J Film Capacitor Specifications:
- Capacitance: 25 uF
- Capacitance Tolerance: 5%
- Voltage AC: 470 VAC
- Max dVidt: 15 V us
- Dimensions: Diameter 40mm +1mm, length approximately 40mm
- Material: Film/Foil Polypropylene dielectric
- Mounting: Bolt-M8x33
- Rating Temperature: 85°C
- Temperature Range: -25/+85°C
- Weight: 112g
- Sealing: Sonically welded seal
- Flammability: UL 94 VO
- RoHS: Yes
Buy the Buy KEMET Capacitors Part Number C276CC35250AA1J Online
Enhance your industrial projects with this high-quality film capacitor. Featuring 25 uF capacitance, 470 VAC rating, sonically welded seal, UL-94 VO flammability, RoHS compliance, and robust polypropylene dielectric. Its compact size of 40mm diameter and 40mm length ensures easy installation in motor run and high-voltage applications. Built for reliability, it operates within -25°C to +85°C temperature range, providing dependable service in demanding industrial environments. Purchase online today for superior performance and peace of mind in your critical applications.
Buy KEMET C276CC35250AA1J now and experience unmatched reliability and high-voltage performance for industrial motor applications.
Frequently Asked Questions
Where can I buy KEMET C276CC35250AA1J?
You can click on the BUY or RFQ button to purchase C276CC35250AA1J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C276CC35250AA1J?
You can download the C276CC35250AA1J datasheet or visit the KEMET website for support.
Who is the manufacturer of C276CC35250AA1J?
KEMET
