KEMET C330C334KBR5TA High-Voltage Ceramic Capacitor
The GoldMax 300 Comm X7R HV capacitor is a high-voltage ceramic component featuring a capacitance of 0.33 uF with a tolerance of 10%. Designed for industrial and commercial applications, it operates reliably within a temperature range of -55°C to +125°C and withstands up to 630 VDC. It has a dielectric with a rated voltage of 945 VDC, low dissipation factor of 2.5% at 1 kHz, and an insulation resistance of 3.03 GOhms. Its radial style includes lead spacing of 5.08mm and dimensions up to 9.14mm MAX and 7.62mm MAX, suitable for various high-voltage electronic circuits and manufacturing needs.
KEMET C330C334KBR5TA High-Voltage Ceramic Capacitor Specifications:
- Capacitance: 0.33 uF
- Capacitance Tolerance: 10%
- Voltage DC: 630 VDC
- Dielectric: X7R, rated 945 VDC
- Temperature Range: -55°C to +125°C
- Dissipation Factor: 2.5% at 1 kHz 1.0 Vrms
- Insulation Resistance: 3.03 GOhms
- Lead Spacing: 5.08 mm
- Dimensions: Max 9.14 mm length, Max 7.62 mm width
- Packaging: Bulk, Bag
- Quantity: 250 pieces
Buy the KEMET Series GoldMax HV Ceramic Capacitor: C330C334KBR5TA
Purchase the KEMET C330C334KBR5TA ceramic capacitor online today for your high-voltage electronic projects. This reliable, high-performance component features a capacitance of 0.33 uF and operates at 630 VDC, making it ideal for industrial applications. Its X7R dielectric ensures stable performance over a broad temperature range of -55°C to +125°C. With a low dissipation factor of 2.5% at 1 kHz and robust insulation resistance, this capacitor is designed for durability and precision. Order now to equip your electronic systems with trusted quality from KEMET.
Get KEMET C330C334KBR5TA today—built for high-voltage reliability and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET C330C334KBR5TA?
You can click on the BUY or RFQ button to purchase C330C334KBR5TA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C330C334KBR5TA?
You can download the C330C334KBR5TA datasheet or visit the KEMET website for support.
Who is the manufacturer of C330C334KBR5TA?
KEMET
