KEMET C331C472KGR5TA Ceramic Capacitor
The KEMET C331C472KGR5TA is a GoldMax 300 Comm X7R HV ceramic capacitor, engineered for robust performance in commercial and industrial applications. Featuring a capacitance of 4700 pF, a wide temperature range of -55°C to +125°C, and a high voltage rating of 2000 VDC, this capacitor is suitable for power supplies, renewable energy systems, and other critical applications. Its X7R dielectric provides excellent stability over temperature, ensuring consistent performance. The capacitor's robust construction and reliable characteristics make it a preferred choice for demanding electronic designs.
KEMET C331C472KGR5TA Ceramic Capacitor Specifications:
- Series: GoldMax 300 Comm X7R HV
- Style: Radial
- Description: GoldMax, Commercial Standard
- RoHS: Yes
- Termination: Tin
- AEC-Q200: No
- Halogen Free: Yes
- L: 7.62mm MAX
- H: 9.14mm MAX
- T: 6.35mm MAX
- S: 6.35mm +/-0.78mm
- LL: 7mm MIN
- F: 0.51mm +0.1/-0.025mm
- Packaging: Bulk, Bag
- Packaging Quantity: 250
- Capacitance: 4700 pF
- Measurement Condition: 1 kHz 1.0Vrms
- Capacitance Tolerance: 10%
- Voltage DC: 2000 VDC
- Dielectric Withstanding Voltage: 2400 VDC
- Temperature Range: -55/+125°C
- Temperature Coefficient: X7R
- Capacitance Change with Reference to +25°C and 0 VDC Applied(TCC): 0.15, 1kHz 1.0Vrms
- Dissipation Factor: 2.5% 1 kHz 1.0Vrms
- Aging Rate: 3% Loss/Decade Hour
- Insulation Resistance: 100 GOhms
