KEMET C44PMGR5600RBSJ Power Filter Capacitor
The KEMET C44P-R series metallized polypropylene film capacitor offers reliable filtering performance for AC applications. With 60 uF capacitance, 5% tolerance, 480 VAC rating, and 1100 VDC withstand voltage, it is designed for power factor correction and AC filtering. Its compact can style features threaded M10 studs for secure mounting, making it suitable for industrial, HVAC, and power electronics. The capacitor operates efficiently over a temperature range of -25°C to +70°C and features a low ripple current of 30 Amps. Its rugged construction ensures durability in demanding environments, with dimensions of approximately 65mm diameter and 147mm length.
KEMET C44PMGR5600RBSJ Power Filter Capacitor Specifications:
- Capacitance: 60 uF
- Tolerance: 5%
- Voltage AC: 480 VAC
- Voltage DC: 1100 VDC
- Operating Temperature: -25°C to +70°C
- Dimensions: Diameter 65mm ±0.5mm, Length 147mm ±2mm
- Mounting: Bolt - M12x16
- Ripple Current: 30 Amps (10kHz, 40°C)
- Leakage Resistance: 3.8 mOhms (10kHz)
- Inner Dielectric: Metallized Polypropylene
- Features: Can style, Single Phase PFC, RoHS compliant
- Thermal Resistance: 5.9°C/W
- Inductance: 140 nH
- dV/dt: 20 V/μs
Buy the KEMET C44P-R – Reliable Power Filter Capacitor for Industrial Applications
Upgrade your electrical systems with the KEMET C44P-R power filter capacitor, ideal for AC power correction, filtering, and industrial applications. Featuring 60 uF capacitance, 480 VAC rating, and 1100 VDC withstand voltage, it ensures reliable operation. Its compact can design with threaded M10 studs allows easy installation in various environments. Designed for robustness, it operates efficiently within -25°C to +70°C temperature ranges, with low ripple current. Buy online now to ensure your power systems are protected with premium quality capacitors for long-lasting performance.
Order your KEMET SeriesC44P-R capacitor today and enhance your power filtering and correction solutions with proven reliability and durability.
