KEMET C44PMGR5800RASJ Power Filter Capacitor
The C44P-R is a metallized polypropylene film capacitor designed for AC filtering applications. It features a 80 uF capacitance with a 5% tolerance, rated for 480 VAC and 1100 VDC. This can-type capacitor includes threaded M10 studs for mounting, with dimensions of 75mm diameter and 147mm length. It operates effectively within a temperature range of -25°C to +70°C and supports a ripple current of 50 Amps at 10kHz. Its robust construction makes it suitable for single-phase power factor correction and other filtering tasks in industrial environments.
KEMET C44PMGR5800RASJ Power Filter Capacitor Specifications:
- Capacitance: 80 uF
- Capacitance Tolerance: 5%
- Voltage AC: 480 VAC
- Voltage DC: 1100 VDC
- Dimensions: Diameter 75mm ±0.5mm, Length 147mm ±2mm
- Operating Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Mounting: Bolt - M12x16 Max
- Resistance: 1.4 mOhms at 10kHz
- Ripple Current: 50 Amps at 10kHz, 40°C
- Inductance: 150 nH
- Thermal Resistance: 5.3°C/W
- Dmax: 75mm ±0.5mm
- Lead: Threaded Studs M10
- RoHS Compliant, REACH SVHC: Pb CAS 7439-92-1
- Packaging: Bulk, Bag
- D V/dt: 20 V/μs
Buy the Buy KEMET AC Filter Part Number C44PMGR5800RASJ Online
Enhance your power systems with the KEMET C44PMGR5800RASJ, a high-quality metallized polypropylene film capacitor. With 80 uF capacitance, rated for 480 VAC and 1100 VDC, this can-type capacitor features threaded M10 studs for easy mounting. Its robust construction supports a ripple current of 50 Amps and operates efficiently within -25°C to +70°C temperature range. Perfect for single-phase PFC and AC filtering, it ensures reliable performance in industrial applications, available for quick online purchase.
Buy KEMET C44PMGR5800RASJ now and experience unmatched reliability and performance in power filtering applications.
Frequently Asked Questions
Where can I buy KEMET C44PMGR5800RASJ?
You can click on the BUY or RFQ button to purchase C44PMGR5800RASJ from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PMGR5800RASJ?
You can download the C44PMGR5800RASJ datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PMGR5800RASJ?
KEMET
