KEMET C44PRGR5220RASK Film Capacitor
The C44P-R is a metallized polypropylene film capacitor designed for AC filtering applications. It offers a capacitance of 22 microfarads with a 10% tolerance, supporting a voltage of 640 VAC and 1400 VDC. The capacitor features a can style construction with threaded M10 studs for secure mounting. It has a temperature range from -25°C to +70°C, with a thermal resistance of 10.1°C/W. Its compact dimensions include a diameter of 65mm, length of 147mm, width of 18mm, height of 28mm, and a body width of 40mm, suitable for single-phase power factor correction and filtering applications.
KEMET C44PRGR5220RASK Film Capacitor Specifications:
- Capacitance: 22 uF
- Capacitance Tolerance: 10%
- Voltage AC: 640 VAC
- Voltage DC: 1400 VDC
- Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Max dVidt: 30 Vius
- Resistance: 2.9966439 mOhms at 10kHz
- Ripple Current: 30 Amps at 10kHz 40°C
- Inductance: 125 nH
- Dimensions: Diameter 65mm, Length 147mm, Width 18mm, Height 28mm, Body Width 40mm
- Mounting: M12x16 bolt, threaded studs M10
- Material: Metallized Polypropylene
- Style: Can
- Features: Single Phase PFC
- Temperature Range: -25°C to +70°C
- Thermal Resistance: 10.1°C/W
Buy the Buy KEMET Film Cap Part Number C44PRGR5220RASK Online
Order the KEMET C44PRGR5220RASK film capacitor online today for reliable AC filtering and power factor correction. This high-quality metallized polypropylene capacitor supports 640 VAC and 1400 VDC, making it ideal for industrial applications requiring durable and efficient components. Its compact design with threaded M10 studs ensures easy installation. The capacitor's wide temperature range from -25°C to +70°C, along with a thermal resistance of 10.1°C/W, guarantees stability and consistent performance in demanding environments. Purchase now for quick delivery and excellent technical support.
Buy KEMET C44PRGR5220RASK now and experience unmatched reliability and high-performance AC filtering with robust can construction and threaded studs.
