KEMET C44PUGR5330RASK Power Filter Capacitor
The KEMET C44P-R series is a high-quality film capacitor with metallized polypropylene dielectric, designed for AC filtering applications. Featuring 33 µF capacitance with 10% tolerance, it supports 780 VAC and 1700 VDC voltages, making it suitable for power factor correction and industrial use. Its robust construction includes threaded M10 studs, a can style body, and a temperature range of -25°C to +70°C. With a thermal resistance of 7.1°C/W and inductance of 150 nH, this capacitor offers reliable performance in demanding electrical systems, endorsed by RoHS compliance and rated at 70°C.
KEMET C44PUGR5330RASK Power Filter Capacitor Specifications:
- Capacitance: 33 µF
- Capacitance Tolerance: 10%
- Voltage AC: 780 VAC
- Voltage DC: 1700 VDC
- Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Max dVidt: 70 Vus
- Resistance: 2.03125 mOhms (10kHz)
- Ripple Current: 42 Amps (10kHz, 40°C)
- Inductance: 150 nH
- Dimensions: D 85 mm ±0.5 mm, L 147 mm ±2 mm, W 24 mm ±1 mm
- Mounting: Bolt M12x16
- Packaging: Bulk, Bag
- Material: Metallized Polypropylene
- Series: C44P-R
- Features: Single Phase PFC
- RoHS: Compliant with exemptions
- Lead: Threaded Studs M10
- Thermal Resistance: 7.1°C/W
Buy the Buy KEMET C44PUGR5330RASK Part Number 33uF AC Filter Capacitor Online
Discover the high-performance KEMET power filter capacitor designed for demanding power systems. Featuring 33 microfarads and supporting up to 780 volts AC and 1700 volts DC, this robust capacitor ensures excellent power quality and reliability. Its metallized polypropylene dielectric provides durability and stability, ideal for industrial power factor correction and filtering applications. Easy to install with threaded M10 studs and packaged for convenience, it’s the perfect solution for engineers seeking high voltage, high capacitance, and precision performance in demanding environments.
Order your KEMET Series C44PUGR5330RASK high-voltage power capacitor today and ensure reliable power filtering in industrial and commercial systems.
Frequently Asked Questions
Where can I buy KEMET C44PUGR5330RASK?
You can click on the BUY or RFQ button to purchase C44PUGR5330RASK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PUGR5330RASK?
You can download the C44PUGR5330RASK datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PUGR5330RASK?
KEMET
