KEMET C44PXGR5150RASK Film Capacitor
The KEMET C44P-R is a high-performance film capacitor designed for AC filtering applications, featuring metallized polypropylene dielectric which ensures reliable operation. It is rated at 15 microfarads with a 10% tolerance, capable of handling 1000 VAC and 2300 VDC voltages, making it suitable for various industrial and power electronics applications. The robust can style construction includes M10 threaded studs for secure mounting, and the capacitor operates within a temperature range of -25°C to +70°C. Its specifications include a ripple current of 32 Amps, low inductance of 150 nH, and a thermal resistance of 9.4°C/W, ensuring durability and stability under demanding conditions.
KEMET C44PXGR5150RASK Film Capacitor Specifications:
- Capacitance: 15 uF
- Capacitance Tolerance: 10%
- Voltage AC: 1000 VAC
- Voltage DC: 2300 VDC
- Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Max dVidt: 85 V rms
- Resistance: 2.5313789 mOhms at 10 kHz
- Ripple Current: 32 Amps at 10 kHz, 40°C
- Inductance: 150 nH
- Dimensions: D 75mm ±0.5mm, L 147mm ±2mm, W 24mm ±1mm, S 35mm ±1mm, Wi 45mm ±1mm
- Mounting: M12 Bolt
- Component Weight: 700g
- Thermal Resistance: 9.4°C/W
- Style: Can
- Dielectric: Metallized Polypropylene
- Features: Single Phase PFC
- RoHS: Compliant with exemptions
- REACH: SVHC (Pb - CAS 7439-92-1)
Buy the Buy KEMET Film Capacitor Part Number C44PXGR5150RASK Online
Purchase the KEMET C44PXGR5150RASK film capacitor online today—engineered for reliable power filtering, capable of withstanding high voltages. Its metallized polypropylene dielectric ensures excellent performance and stability in industrial applications. Designed with M12 mounting studs for easy installation, it offers a capacitance of 15 microfarads with a 10% tolerance, rated at 1000 VAC and 2300 VDC. This robust component features a temperature range from -25°C to +70°C, low inductance of 150 nH, and high ripple current capacity of 32 Amps, making it ideal for demanding power electronics systems.
Get KEMET C44PXGR5150RASK today—built for power filtering precision and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET C44PXGR5150RASK?
You can click on the BUY or RFQ button to purchase C44PXGR5150RASK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PXGR5150RASK?
You can download the C44PXGR5150RASK datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PXGR5150RASK?
KEMET
