KEMET C44PXGR5330RASK Film Capacitor
The C44P-R series film capacitor features metallized polypropylene dielectric and is designed for single-phase power factor correction applications. With a capacitance of 33 microfarads ±10%, it tolerates voltage up to 1000 VAC and 2300 VDC, ensuring reliable performance in industrial environments. The can style construction includes threaded M10 studs for secure mounting, with dimensions of approximately 75mm in diameter, 247mm in length, and other features tailored for high electrical stability. Rated for -25/+70°C, it offers excellent thermal resistance and low equivalent series resistance for optimal energy efficiency.
KEMET C44PXGR5330RASK Film Capacitor Specifications:
- Capacitance: 33 uF
- Capacitance Tolerance: 10%
- Voltage AC: 1000 VAC
- Voltage DC: 2300 VDC
- Temperature Range: -25/+70°C
- Rated Temperature: 70°C
- Dimensions: Diameter 75mm ±0.5mm, Length 247mm ±2mm, Width 24mm ±1mm, Stud Length 35mm, Width 45mm
- Mounting: Bolt M10
- Resistance: 1.6555134 mOhms (LOkHz)
- Ripple Current: 40 Amps (LOkHz 40°C)
- Thermal Resistance: 5.3 CW
Buy the Buy KEMET Film Capacitor Part Number C44PXGR5330RASK Online
Purchase the KEMET C44PXGR5330RASK film capacitor online today for your industrial applications. This reliable component features a 33uF capacitance, 1000VAC and 2300VDC voltage ratings, and a robust M10 threaded stud mount for secure installation. Designed for single-phase PFC circuits, it withstands temperatures from -25°C to +70°C and offers low resistance and high ripple current capacity. Perfect for power factor correction in industrial and commercial systems, ensuring efficiency and long-term durability in demanding conditions.
Get KEMET C44PXGR5330RASK today—built for durability and high-performance power correction.
Frequently Asked Questions
Where can I buy KEMET C44PXGR5330RASK?
You can click on the BUY or RFQ button to purchase C44PXGR5330RASK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PXGR5330RASK?
You can download the C44PXGR5330RASK datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PXGR5330RASK?
KEMET
