KEMET C44UHGT7130M86K Industrial Film Capacitor
The C44U-M is a high-capacity film capacitor series crafted from metallized polypropylene, ideal for DC filtering and energy storage applications. Designed with screw terminals M6 and a bolt mounting system (M12x16), it features a capacitance of 1300 uF, rated voltage of 600 VDC, and operates within a temperature range of -40°C to +85°C. Its dimensions include a diameter of approximately 85mm, length around 178.5mm, and weight of 6600 grams. It also offers low resistance of 1.1 mOhms at 10kHz, with a maximum dV/dt of 5 V/μs, making it suitable for robust industrial use.
KEMET C44UHGT7130M86K Industrial Film Capacitor Specifications:
- Capacitance: 1300 uF
- Voltage DC: 600 VDC
- Dielectric: Metallized Polypropylene
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter approximately 85mm, length around 178.5mm
- Weight: 6600 grams
- Mounting: Bolt M12x16
- Resistance: 1.1 mOhms at 10kHz
- Ripple Current: 84 Amps at 10kHz, 40°C
- Inductance: 60 nH
- Insulation Resistance: 20 MOhms
- Thermal Resistance: 3.8°C/W
- Maximum dV/dt: 5 V/μs
- Rated Temperature: 75°C
- Packaging: Bulk, Bag, Quantity: 5
Buy the KEMET C44UHGT7130M86K – Reliable Capacitor for Industrial Applications
Order the KEMET C44UHGT7130M86K online today to ensure your industrial energy storage and filtering systems operate smoothly and efficiently. This high-capacity film capacitor features a robust design with 1300 uF capacitance, 600 VDC rating, and durable screw terminals, suitable for demanding environments. Its compact dimensions, low resistance, and high ripple current capacity make it ideal for industrial applications requiring stability and reliability. Secure your supply today for superior performance and long-term operational efficiency.
Buy KEMET C44UHGT7130M86K now and experience unmatched reliability and performance in high-voltage industrial filtering and energy storage applications.
Frequently Asked Questions
Where can I buy KEMET C44UHGT7130M86K?
You can click on the BUY or RFQ button to purchase C44UHGT7130M86K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UHGT7130M86K?
You can download the C44UHGT7130M86K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UHGT7130M86K?
KEMET
