KEMET C44UHGT7210M87K high-voltage film capacitor
The C44U-M series film capacitor by KEMET features metallized polypropylene dielectric, designed for DC filtering and energy storage applications. With a capacitance of 2100 uF and a voltage rating of 600 VDC, it is suitable for high-voltage, industrial power systems. The can-style design includes screw terminals M6 for secure mounting. It provides excellent thermal resistance, low ESR of 1.7 mOhms at 10kHz, and ripple currents up to 82 Amps at 40°C. Its compact dimensions are approximately 85mm in diameter and 269mm in length, making it ideal for demanding power electronics.
KEMET C44UHGT7210M87K high-voltage film capacitor Specifications:
- Capacitance: 2100 uF
- Voltage DC: 600 VDC
- Dielectric: Metallized Polypropylene
- Style: Can
- Lead Terminals: Screw, M6
- Dimensions: Diameter 85mm +2mm, Length 268.5mm +/-2mm
- Temperature Range: -40/+85°C
- Thermal Resistance: 2.6°C/W
- Insulation Resistance: 10 MOhms
- Ripple Current: 82 Amps (L0kHz 40°C)
- Resistance: 1.7 mOhms (10kHz)
- Inductance: 80 nH
- Maximum dV/dt: 3 V/μs
- Rated Temperature: 75°C
- Mounting: Bolt M12x16
- Packaging: Bulk, Bag
- Component Weight: 1840 g
Buy the KEMET C44UHGT7210M87K – Reliable Energy Storage Capacitor for Industrial Applications
Enhance your industrial power systems with the KEMET high-voltage film capacitor. Featuring 2100 uF capacitance, 600 VDC rating, and robust can-style design, it offers superior energy storage, excellent thermal resistance, and high ripple current handling. Ideal for DC filtering in demanding applications, its screw terminals M6 ensure secure mounting. Compact yet powerful, this capacitor meets industry standards and performs reliably in diverse environments, making it the perfect choice for engineers seeking quality, durability, and efficiency in power electronics.
Order your KEMET Series C44UHGT7210M87K high-voltage capacitor today and ensure your power systems operate reliably with superior energy storage and filtering capability.
Frequently Asked Questions
Where can I buy KEMET C44UHGT7210M87K?
You can click on the BUY or RFQ button to purchase C44UHGT7210M87K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UHGT7210M87K?
You can download the C44UHGT7210M87K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UHGT7210M87K?
KEMET
