KEMET C44UOGT6350A8SK High Voltage Film Capacitor
The C44U series is a heavy-duty metallized polypropylene film capacitor designed for high-voltage DC link applications. It features a can style construction with screw terminals M6, capable of handling a capacitance of 350 uF with 10% tolerance at a voltage of 900 VDC. Suitable for demanding environments, this capacitor operates within a temperature range of -40°C to +85°C and is rated for a maximum temperature of 75°C. Its robust design makes it ideal for power conversion, energy storage, and industrial high-voltage systems, ensuring reliable performance and long service life.
KEMET C44UOGT6350A8SK High Voltage Film Capacitor Specifications:
- Capacitance: 350 uF
- Capacitance Tolerance: 10%
- Voltage DC: 900 VDC
- Temperature Range: -40°C to +85°C
- Rated Temperature: 75°C
- Dimensions: Diameter 31.7mm ±0.2mm, Length 146mm ±2mm
- Mounting: Bolt M12x16
- Insulation Resistance: 90 MOhms
- Dissipation Factor: 7 V/us
- Equivalent Series Resistance: 3 mOhms (10kHz)
- Ripple Current: 2450
- Inductance: 60 nH
- Thermal Resistance: 4.1°C/W
- Weight: 833 grams
- Material: Metallized Polypropylene
- Lead Terminals: M6 screw terminals
Buy the Buy KEMET Metallized Polypropylene Capacitor Part Number C44UOGT6350A8SK Online
Purchase the KEMET C44U series high-voltage metallized polypropylene film capacitor online today. Designed for demanding applications, it offers 350 uF capacitance at 900 VDC with a wide operating temperature range of -40°C to +85°C. Its robust can style construction with M6 screw terminals ensures secure mounting and excellent electrical performance. Ideal for power conversion, energy storage, and industrial systems, this capacitor delivers dependable operation, efficient energy handling, and long-term durability, making it your ideal high-voltage solution.
Get KEMET C44UOGT6350A8SK today—built for high-voltage power supply systems and industrial applications with reliable, long-lasting performance.
Frequently Asked Questions
Where can I buy KEMET C44UOGT6350A8SK?
You can click on the BUY or RFQ button to purchase C44UOGT6350A8SK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UOGT6350A8SK?
You can download the C44UOGT6350A8SK datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UOGT6350A8SK?
KEMET
