KEMET C44UOGT7180M53K High-Voltage Film Capacitor
The C44U-M series is a high-capacity metallized polypropylene film capacitor designed for DC link applications, energy storage, and filtering. With a capacitance of 1800 uF and a voltage rating of 900 VDC, it operates efficiently within a temperature range of -40°C to +85°C. The can-style component features screw terminals M6 for secure mounting. Its dimensions include a diameter of approximately 116mm ±2mm, a length of 233mm ±2mm, and a height of 236mm ±2mm. Rated for high ripple current and resistance of 1.2 mOhms at 10kHz, it ensures reliable performance in demanding environments.
KEMET C44UOGT7180M53K High-Voltage Film Capacitor Specifications:
- Capacitance: 1800 uF
- Voltage DC: 900 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 116mm ±2mm, Length 233mm ±2mm, Height 236mm ±2mm
- Material: Metallized Polypropylene
- Mounting: Bolt - M6 screw terminals
- Insulation Resistance: 20 MOhms
- Ripple Current: 200 Amps at 40°C, 10kHz
- Resistance: 1.2 mOhms at 10kHz
- Rated Temperature: 75°C
- Maximum dV/dt: 7 V/μs
- Thermal Resistance: 2.1°C/W
- Packaging: Bulk, Bag
- Lead Type: Screw Terminals M6
Buy the YAGEO Series C44U-M Metalized Polypropylene Capacitor: C44UOGT7180M53K
Discover the reliability and excellent performance of the YAGEO C44UOGT7180M53K high-voltage film capacitor, ideal for DC link and energy storage applications. With a capacitance of 1800 uF and a voltage rating of 900 VDC, it is suitable for demanding industrial environments. Its robust construction, screw terminals, and broad temperature range (-40°C to +85°C) make it perfect for high ripple current, filtering, and energy storage. Purchase online now and ensure your projects benefit from proven power management components, backed by quality and performance standards.
Order your YAGEO Series C44UOGT7180M53K high-voltage film capacitor today and ensure reliable energy storage and filtering for demanding power applications.
