KEMET C44UQGT6290M82K High-Voltage Film Capacitor
The KEMET C44UQGT6290M82K is a high-voltage film capacitor with a capacitance of 290 uF and a voltage rating of 1100 VDC, tailored for DC filtering and energy storage applications. It features a metallized polypropylene dielectric in a can-style housing, with screw terminal M6 connections. This capacitor operates within a temperature range of -40°C to +85°C and is designed for reliable performance in industrial and power electronics. Its robust construction and low inductance of 50 nH make it suitable for demanding electrical environments, ensuring efficiency and stability.
KEMET C44UQGT6290M82K High-Voltage Film Capacitor Specifications:
- Capacitance: 290 uF
- Voltage DC: 1100 VDC
- Dielectric: Metallized Polypropylene
- Style: Can
- Mounting: Bolt M12x16
- Temperature Range: -40°C to +85°C
- Insulation Resistance: 100 MOhms
- Resistance: 2.1 mOhms at 10kHz
- Ripple Current: 47 Amps at 10kHz, 40°C, 2880 Amps Peak
- Inductance: 50 nH
- Dimensions: D 85mm +2mm, L 114.5mm +/-2mm, La 116mm +/-2mm
- Thermal Resistance: 6.4°C/W
- Weight: 960 grams
- Packaging: Bulk, Bag
- Rated Temperature: 75°C
- Maximum dVidt: 10 V
- Insulation Resistance: 100 MOhms
Buy the KEMET C44UQGT6290M82K – Reliable Film Capacitor for Industrial Applications
Order the KEMET C44UQGT6290M82K high-voltage film capacitor online today and benefit from superior performance in DC filtering and energy storage applications. With a capacitance of 290 uF and a voltage rating of 1100 VDC, this robust capacitor features metallized polypropylene dielectric and can withstand temperatures from -40°C to +85°C. Its screw terminal M6 design and low inductance ensure excellent stability and efficiency in power electronics. Purchase now for reliable operation in demanding industrial environments and elevate your electrical systems' performance.
Buy KEMET C44UQGT6290M82K now and experience unmatched reliability and high-voltage performance for industrial electronics.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6290M82K?
You can click on the BUY or RFQ button to purchase C44UQGT6290M82K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6290M82K?
You can download the C44UQGT6290M82K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6290M82K?
KEMET
