KEMET C44UQGT6320M83K High-Voltage Film Capacitor
The C44U-M series film capacitor by KEMET is a high-voltage metallized polypropylene capacitor designed for DC filtering and energy storage applications. Featuring a can style construction, it offers a capacitance of 320 uF with 10% tolerance, rated for 1100 VDC. Suitable for demanding environments, it operates at -40/+85°C with a thermal resistance of 5.8°C/W. The component includes M6 screw terminals, measures approximately 85mm in diameter and 124.5mm in length, and is packaged in bulk for industrial use, ensuring reliable performance in power conversion, inverter, and filtering systems.
KEMET C44UQGT6320M83K High-Voltage Film Capacitor Specifications:
- Capacitance: 320 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1100 VDC
- Operating Temperature Range: -40°C to +85°C
- Dimensions: Diameter 85mm +2mm, Length 124.5mm +/-2mm
- Thermal Resistance: 5.8°C/W
- Insulation Resistance: 90 MOhms
- Mounting: Bolt - M12x16
- Weight: 5100 grams
- Resistance at 10kHz: 2.4 mOhms
- Ripple Current: 46 Amps at 10kHz (40°C)
- Inductance: 50 nH
- Max dV/dt: 9 V/us
- Packaging: Bulk, Bag
- RoHS: Compliant with exemptions
- Lead Terminals: M6 screw terminals
Buy the Buy KEMET C44UQGT6320M83K Part Number C44UQGT6320M83K Online
Purchase the KEMET C44UQGT6320M83K high-voltage film capacitor online today. With a capacitance of 320 uF and voltage rating of 1100 VDC, it is ideal for energy storage, filtering, and power conversion applications. Its robust design features M6 screw terminals, a can style aluminum case, and operates efficiently over -40°C to +85°C temperatures. Suitable for demanding industrial environments, this capacitor ensures long-lasting durability and excellent electrical performance, making it the perfect choice for engineers seeking reliable and high-quality power components.
Get KEMET C44UQGT6320M83K today—built for high-voltage energy storage and reliable power filtering performance.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6320M83K?
You can click on the BUY or RFQ button to purchase C44UQGT6320M83K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6320M83K?
You can download the C44UQGT6320M83K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6320M83K?
KEMET
