KEMET C44UQGT6400M85K Energy Storage Capacitor
This high-capacity DC link capacitor features a metallized polypropylene dielectric, offering 400 uF capacitance with a 10% tolerance and a voltage rating of 1100 VDC. Designed in a can style, it is ideal for energy storage and DC filtering applications in industrial and power conversion systems. Its robust construction ensures reliable performance across temperatures from -40°C to +85°C, with low resistance of 2.8 mOhms at 10 kHz and a thermal resistance of 5.1°C/W. The unit mounts with M12x16 bolts and is packaged in bulk for convenient installation.
KEMET C44UQGT6400M85K Energy Storage Capacitor Specifications:
- Capacitance: 400 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1100 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 85mm +2mm, Length 144.5mm +/-2mm, La 146mm +/-2mm, s 32mm +/-0.3mm
- Mounting: Bolt - M12x16
- Insulation Resistance: 80 MOhms
- Thermal Resistance: 5.1°C/W
- Max dVidt: 7 V/us
- Resistance: 2.8 mOhms at 10kHz
- Ripple Current: 45 Amps at 10kHz, Peak 2920 Amps
- Inductance: 55 nH
- Weight: 1120 g
- Packaging: Bulk, Bag
- RoHS: Compliant with Exemptions
- REACH: SVHC included
Buy the KEMET C44UQGT6400M85K – Reliable Energy Storage Capacitor for Industrial Applications
Secure your power systems with the KEMET C44UQGT6400M85K high-capacity film capacitor. Featuring 400 uF at 1100 VDC, it’s perfect for industrial energy storage and filtering. Its robust can style ensures durability, with a temperature range from -40°C to +85°C. Mount it easily with M12 bolts and enjoy low resistance of 2.8 mOhms. Packaged in bulk for quick deployment, this capacitor guarantees reliable performance in demanding electrical applications, making it an essential component for power conversion and energy management systems.
Buy KEMET C44UQGT6400M85K now and enhance your energy storage and filtering systems with top-grade film capacitors designed for demanding industrial environments.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6400M85K?
You can click on the BUY or RFQ button to purchase C44UQGT6400M85K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6400M85K?
You can download the C44UQGT6400M85K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6400M85K?
KEMET
