KEMET C44UQGT7140M54K DC Link Capacitor
The KEMET C44UQGT7140M54K is a high-capacity metallized polypropylene film capacitor designed for DC link applications. It features a 1400 uF capacitance, 10% tolerance, and operates at 1100 VDC. With screw terminal mounting and robust construction, it provides reliable DC filtering and energy storage in industrial power systems. The capacitor withstands temperatures from -40 to +85°C, maintains an insulation resistance of 20 MOhms, and supports ripple currents up to 100 Amps. Its compact can style measures 16x10 mm, making it ideal for high-voltage energy storage needs.
KEMET C44UQGT7140M54K DC Link Capacitor Specifications:
- Capacitance: 1400 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1100 VDC
- Temperature Range: -40°C to +85°C
- Insulation Resistance: 20 MOhms
- Dimensions: Diameter 119mm +0.5mm, Length 273mm +/-2mm, Can style 16x10mm
- Mounting: Bolt - M12x16
- Ripple Current: 100 Amps
- Resistance: 1.6 mOhms (at 10kHz)
- Inductance: 80 nH
- Maximum dV/dt: 7 V/us
- Thermal Resistance: 1.8 C/W
- Weight: 32709 grams
- Packaging: Bulk, Bag, Quantity: 4
Buy the KEMET C44UQGT7140M54K – Reliable DC Link Capacitor for Industrial Applications
Purchase the KEMET C44UQGT7140M54K online today for your industrial power systems. This high-capacity metallized polypropylene capacitor offers a robust 1400 uF capacitance at 1100 VDC, ensuring efficient energy storage and stable DC filtering. Designed with screw terminals and a compact can style, it provides dependable performance across a wide temperature range. Ideal for large-scale industrial applications, it supports high ripple currents, features low inductance, and maintains excellent insulation resistance. Order now for reliable, long-lasting power management in your systems.
Get KEMET C44UQGT7140M54K today—built for high-voltage DC filtering and reliable energy storage in industrial systems.
