KEMET C44USGT6120M81K High-Voltage Film Capacitor
The C44USGT6120M81K is a high-capacity metallized polypropylene film capacitor designed for DC link applications, energy storage, and filtering in industrial systems. It boasts a voltage rating of 1500 VDC, a capacitance of 120 uF with a 10% tolerance, and operates within a temperature range of -40°C to +85°C. Suitable for bolt mounting with M12x16 bolts, it features screw terminals, low resistance of 2.5 mOhms at 10kHz, and a thermal resistance of 7.1 C/W. Its robust construction and RoHS compliance make it ideal for demanding power electronics.
KEMET C44USGT6120M81K High-Voltage Film Capacitor Specifications:
- Dielectric: Metallized Polypropylene
- Capacitance: 120 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1500 VDC
- Temperature Range: -40°C to +85°C
- Maximum Operating Temperature: 75°C
- Mounting: Bolt M12x16
- Lead: Screw Terminals M6
- Insulation Resistance: 250 MOhms
- Dimension D: 85mm +2mm
- Dimension L: 99.5mm +/-2mm
- Insulation Resistance: 250 MOhms
- Ripple Current: 41 Amps at 10kHz, 40°C, 2030 Peak Amps
- Inductance: 50 nH
- Resistance: 2.5 mOhms at 10kHz
- Thermal Resistance: 7.1 C/W
- Packaging: Bulk, Bag
- Weight: 880g
- Maximum dVidt: 17 Vus
Buy the KEMET Series C44U-M High-Voltage Film Capacitor: C44USGT6120M81K
Order the KEMET C44USGT6120M81K high-voltage film capacitor online today and ensure your power systems operate reliably. Featuring 120 microfarad capacitance, 1500 VDC voltage rating, screw terminal mounting, and excellent thermal performance, this capacitor is ideal for demanding industrial environments. Its robust construction, low resistance, and compliance with RoHS standards make it a trusted choice for energy storage, DC filtering, and power conversion applications. Secure quick delivery and expert support when you purchase online.
Buy KEMET C44USGT6120M81K high-voltage film capacitor now and experience unmatched reliability and power handling in industrial applications.
Frequently Asked Questions
Where can I buy KEMET C44USGT6120M81K?
You can click on the BUY or RFQ button to purchase C44USGT6120M81K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44USGT6120M81K?
You can download the C44USGT6120M81K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44USGT6120M81K?
KEMET
