KEMET CT05 Current Sensor
The KEMET CT series high-performance current sensor is designed for accurate overcurrent and current detection in electrical systems. It features a round toroidal style with wire leads, and is made of phenolic resin with epoxy filling, providing durability and stability. With high sensitivity and reliable performance, it operates within a temperature range of -20°C to +80°C. The sensor has dimensions of approximately 5.5mm diameter, 17.5mm length, and 10mm height. Packaged in trays, it weighs 4.4g and is RoHS compliant, suitable for various industrial and electrical applications.
KEMET CT05 Current Sensor Specifications:
- Temperature Range: -20°C to +80°C
- Materials: Phenolic Resin Case, Epoxy-Filled
- Turns: 500
- Dimensions: Diameter 5.5mm NOM, Length 17.5mm +/-0.4mm, Height 10mm NOM, Overall Length 17.5mm +/-0.4mm, Lead: Wire Leads
- Packaging: Tray with 1200 units, Component Weight: 4.4g
- RoHS: Yes
- Notes: 0.6 mm Diameter Pin Connectors
Buy the KEMET Series CT Current Sensor: CT05
Purchase the KEMET CT series current sensor online today and experience reliable overcurrent and current detection with high sensitivity. Featuring a durable epoxy-filled phenolic resin case and wire leads, this sensor is ideal for industrial, control, and electrical systems requiring accurate current monitoring. Its compact dimensions ensure easy integration into your designs, while the RoHS compliance guarantees environmentally friendly manufacturing. Order now to ensure your systems operate safely and efficiently with this high-performance, reliable current sensor designed for demanding electrical environments.
Get KEMET CT05 today—built for high sensitivity and durable overcurrent detection in electrical applications.
Frequently Asked Questions
Where can I buy KEMET CT05?
You can click on the BUY or RFQ button to purchase CT05 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part CT05?
You can download the CT05 datasheet or visit the KEMET website for support.
Who is the manufacturer of CT05?
KEMET
