KEMET EC25TNU Miniature Signal Relay
The EC25TNU relay is a compact and reliable miniature signal relay suitable for electronic switching systems, PBX, terminal equipment, and telephone systems. It features high insulation, low power consumption, and configurations including non-latch, single coil latch, and double coil latch types. The relay is RoHS compliant, UL recognized, and CSA certified, ensuring safety and quality. Designed for high performance, it offers excellent switching capacity and durability within a small footprint, making it ideal for industrial and commercial electronic applications.
KEMET EC25TNU Miniature Signal Relay Specifications:
- Contact Form: 2 Form
- Contact Material: Silver alloy with gold overlay
- Maximum Switching Voltage: 125 VAC / 220 VDC
- Maximum Switching Current: 2 A (resistive load)
- Insulation Resistance: 1000 MΩ at 500 VDC
- Initial Contact Resistance: 75 mΩ max.
- Operate Time: approx. 2 ms
- Release Time: approx. 1 ms
- Ambient Temperature Range: -40°C to +85°C
- Coil Resistance (nominal): 3 VDC - 64.3Ω, 45 VDC - 203Ω, 5 VDC - 178Ω, 9 VDC - 579Ω, 12 VDC - 1028Ω, 24 VDC - 2880Ω
- Coil Power: 140-230 mW depending on type
- Dimensions: Width approximately 7.5 mm, Length approximately 15 mm
- RoHS Compliant, UL Recognized, CSA Certified, TUV Certificates
- Designed for high reliability with surge capacity and insulation standards
- Suitable for use in safety-critical and industrial electronic switching systems
- Available in various mounting options including tube, embossed tape, and taping for surface mounting.
Buy the NEC EC25TNU – Reliable Signal Relay for Industrial Applications
Discover the NEC EC25TNU miniature signal relay, designed for high reliability and efficient switching in industrial and telecommunications equipment. Its compact size, high insulation, low power consumption, and certified safety standards make it an ideal choice for demanding electronic systems. The relay supports various mounting options and features surge capacity and insulation standards compliant with UL, CSA, and TUV. With excellent switching capacity and durability, buy online today and enhance your system’s performance with trusted NEC quality.
Buy NEC EC25TNU relay now and experience unmatched reliability and performance in your electronic switching systems.
Frequently Asked Questions
Where can I buy KEMET EC25TNU?
You can click on the BUY or RFQ button to purchase EC25TNU from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part EC25TNU?
You can download the EC25TNU datasheet or visit the KEMET website for support.
Who is the manufacturer of EC25TNU?
KEMET
