KEMET ELH228M200AT6AA Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor offers a high capacitance of 2,200 uF with a 20% tolerance, rated at 200 VDC, and operational from -25°C to +85°C. Designed in a snap-in form factor, it features two pins for easy mounting on PCBs, with dimensions of 35mm diameter and 50mm length. Suitable for power supply filtering and energy storage applications, it has a lifespan of 2000 hours, a dissipation factor of 15% at 120Hz, and can handle ripple currents up to 4950 mA. Its RoHS compliance ensures environmentally responsible manufacturing.
KEMET ELH228M200AT6AA Aluminum Electrolytic Capacitor Specifications:
- Series: ELH
- Dielectric: Aluminum Electrolytic
- Description: Snap-In, Aluminum Electrolytic
- RoHS: Yes
- Lead: 2 Pin
- Capacitance: 2,200 uF
- Capacitance Tolerance: 20%
- Voltage DC: 200 VDC, 250 VDC (Surge)
- Temperature Range: -25/+85°C
- Rated Temperature: 85°C
- Life: 2000 Hrs
- Dissipation Factor: 15% 120Hz 20°C
- Resistance: 54 mOhms (20kHz 25°C)
- Ripple Current: 4950 mAmps (120Hz)
- Leakage Current: 3000 uA (5min 20°C)
- Dimensions: D 35mm +1mm, L 50mm +2mm, 10mm +/-0.5mm, LL 5.8mm +/-1mm, F 1.5mm +/-0.1mm
- Packaging: Bulk, Bag, Quantity: 200
Buy the Buy KEMET Aluminum Electrolytic Part Number ELH228M200AT6AA Online
Experience seamless online purchasing of the high-quality aluminum electrolytic capacitor, ideal for power supply filtering and energy storage applications. With a capacitance of 2200 uF, 200 VDC rating, and wide temperature operation from -25°C to +85°C, this snap-in component boasts a lifespan of 2000 hours. Its RoHS compliance and robust construction ensure reliable performance. Purchase now to secure a dependable solution for your electronic designs, with fast delivery and expert support for all your engineering needs.
Buy KEMET ELH228M200AT6AA now and ensure reliable filtering and energy storage with high capacity and durable design.
Frequently Asked Questions
Where can I buy KEMET ELH228M200AT6AA?
You can click on the BUY or RFQ button to purchase ELH228M200AT6AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ELH228M200AT6AA?
You can download the ELH228M200AT6AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ELH228M200AT6AA?
KEMET
