KEMET ELH229M035AS6AA Aluminum Electrolytic Capacitor
The KEMET ELH series aluminum electrolytic capacitor features a 22,000 uF capacitance rating with a 20% tolerance, suitable for filtering and energy storage. Designed with a snap-in aluminum electrolytic construction, it handles a voltage rating of 35 VDC and surge up to 63 VDC, operating reliably within -40°C to +85°C. This capacitor is RoHS compliant, with a typical life of 2000 hours and a dissipation factor of 35% at 120Hz. Its compact dimensions include a diameter of 30mm, length of 50mm, and lead spacing of 5.8mm, making it ideal for various electronic applications.
KEMET ELH229M035AS6AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 22,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 35 VDC, 63 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 30mm, Length 50mm ±2mm
- Lead Spacing: 5.8mm ±0.5mm
- Life: 2000 hours
- Dissipation Factor: 35% at 120Hz, 20°C
- Leakage Current: 3000 uA at 20°C (5 minutes)
- Ripple Current: 6000 mA at 120Hz
- RoHS Compliant: Yes
- Packaging: Bulk, Bag, Quantity: 200
Buy the YAGEO Series ELH Aluminum Electrolytic Capacitor: ELH229M035AS6AA
Purchase the YAGEO ELH Series aluminum electrolytic capacitor ELH229M035AS6AA online today to ensure optimal filtering and energy storage in your electronic designs. With a capacitance of 22,000 uF and a voltage rating of 35 VDC, this component is suited for power supplies, smoothing out voltage fluctuations, and filtering applications. Designed to operate within -40°C to +85°C, it features a 2000-hour lifespan and adheres to RoHS standards, making it an eco-friendly and reliable choice for your projects. Secure your order now and improve your device performance with top-quality components.
Order your YAGEO Series ELH aluminum electrolytic capacitor ELH229M035AS6AA today and give your electronic projects the reliable energy storage they deserve.
Frequently Asked Questions
Where can I buy KEMET ELH229M035AS6AA?
You can click on the BUY or RFQ button to purchase ELH229M035AS6AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ELH229M035AS6AA?
You can download the ELH229M035AS6AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ELH229M035AS6AA?
KEMET
